1-2
Chapter 1: Product introduction
1.1 Welcome!
Thank you for buying an ASUS
®
ASMB8-iKVM server management board!
The ASUS ASMB8-iKVM is an Intelligent Platform Management Interface (IPMI) 2.0-compliant
board that allows you to monitor, control, and manage a remote server from the local
or central server in your local area network (LAN). With ASMB8-iKVM in your server
motherboard, you can completely and efciently monitor your server in real-time. The solution
allows you to reduce IT management costs and increase the productivity.
Before you start installing the server management board, check the items in your package
with the list below.
If any of the above items is damaged or missing, contact your retailer.
1.2 Package contents
Check your server management board package for the following items.
• ASUS ASMB8-iKVM Card
• Support CD
• User guide
