Z10PE-D16 Series specifications summary
Model Name Z10PE-D16/4L Z10PE-D16
Processor Support /
System Bus
2 x Socket R3 2011
Intel
®
Xeon
®
processor E5-2600 V3 product family
QPI 6.4 / 8.0 / 9.6 GTps
Core Logic
Intel
®
C612 PCH
Form Factor
SSI EEB, 12 in. x 13 in.
ASUS
Features
Fan Speed
Control
Rack Ready
(Rack and
Pedestal dual
use)
ASWM
Enterprise
Memory
Total Slots
16 (4 channels per CPU, 2 DIMMs per CPU)
Voltage
1.2 V
Capacity
Maximum up to 1024 GB
Memory Type
DDR4 2133* / 1866 / 1600 / 1333 RDIMM / LR-DIMM / NVDIMM
*Refer to www.asus.com for latest memory AVl updates
Memory Size
4 GB, 8 GB, 16 GB, 32 GB (RDIMM)
32 GB, 64 GB (LR-DIMM)
Expansion
Slots (follow
SSI Location
number)
Total PCI /
PCI-E Slots
5
Slot Location 1
1 x PCI-E x8 (x4 Gen3 link) (MIO supported)
Slot Location 2
1 x PCI-E x16 (x16 Gen3 link)
Slot Location 3
1 x PCI-E x8 (x8 Gen3 link)
Slot Location 4
1 x PCI-E x16 (x16 Gen3 link)
Slot Location 6
1 x PCI-E x16 (x16 Gen3 link)
Networking
LAN
1 x Dual port Intel
®
I350 AM2
Gigabit LAN controller
1 x Dual port Intel
®
I350-BT2
Gigabit LAN controller
1 x Management port
1 x Dual port Intel
®
I350 AM2
Gigabit LAN controller
1 x Management port
(continued on the next page)
