xvi
* Specifications are subject to change without notice.
** Refer to www.asus.com for the complete list of supported PIKE cards.
Z10PE-D16 Series specifications summary
Model Name Z10PE-D16/4L Z10PE-D16
Storage
SATA Controller
Intel
®
C612
10 x SATA 6 Gbps ports
or 9 x SATA 6 Gbps ports + 1 x discrete M.2 connector
Intel
®
RSTe (supports software RAID 0, 1, 5, and 10, Windows only)
LSI
®
MegaRAID (supports software RAID 0, 1, and 10, Linux and
Windows)
SAS Controller
Optional kits**:
ASUS PIKE 3008 8-port SAS 12G RAID card
ASUS PIKE 3108 8-port SAS 12G HW RAID card
Graphic
VGA
Aspeed AST2400 32 MB
Onboard I/O
Connectors
TPM Header
1
PSU Connector
1 x 24-pin SSI power connector + 8-pin SSI 12V + 8-pin SSI 12V
USB Connectors
1 x USB 3.0 pin header (up to 2 devices)
1 x USB 2.0 pin header (up to 2 devices)
Fan Header
9 x 4-pin headers
SMBus
1
Chassis Intruder
1
Front LAN LED
2
Serial Port Header
1
Rear I/O
Connectors
VGA Port
1
External USB Port
2 x USB 3.0
2 x USB 2.0
RJ-45
4 x GbE LAN ports
1 x Management LAN port
2 x GbE LAN ports
1 x Management LAN port
PS/2 KB/Mouse
1
Management
Solution
Software
ASWM Enterprise
Out of Band
Remote
Management
onboard ASMB8-iKVM for KVM-over-Internet
Monitoring
CPU Temperature
FAN RPM
Environment
Operation temperature:
10°C ~ 35°C
Non operation temperature:
-40°C ~ 70°C
Non operation humidity:
20% ~ 90% (Non condensing)
