3-Core Ratio Limit [Auto]

Select [Auto] to apply the CPU default Turbo Ratio setting or manually assign a 3‑Core Limit

value that must be higher than or equal to the 4‑Core Ratio Limit.

If you assign a value for 3‑Core Ratio Limit, do not set the 1‑Core Ratio Limit and 2‑Core

Ratio Limit to [Auto].

4-Core Ratio Limit [Auto]

Select [Auto] to apply the CPU default Turbo Ratio setting or manually assign a 4‑Core Limit

value that must be lower than or equal to the 3‑Core Ratio Limit.

If you assign a value for 4‑Core Ratio Limit, do not set the 1‑Core Ratio Limit, 2‑Core Ratio

Limit, and 3‑Core Ratio to [Auto].

BCLK Frequency: DRAM Frequency Ratio [Auto]

Allows you to set the CPU bus speed to DRAM speed ratio mode.

[Auto] DRAM speed is set to the optimized settings.

[100:133] The BCLK frequency to DRAM speed ratio is set to 100:133.

[100:100] The BCLK frequency to DRAM speed ratio is set to 100:100.

DRAM Odd Ratio Mode [Enabled]

Allows you to enable or disable the Odd Ratio Mode, which provides better granularity.

Conguration options: [Disabled] [Enabled]

DRAM Frequency [Auto]

This item allows you to set the memory operating frequency. The congurable options vary

with the BCLK (base clock) frequency setting. Select the auto mode to apply the optimized

setting. Conguration options: [DDR4‑800MHz] [DDR4‑933MHz] [DDR4‑1066MHz] [DDR4‑

1200MHz] [DDR4‑1333MHz] ~ [DDR4‑4133MHz] [DDR4‑4266MHz]

Selecting a very high memory frequency may cause the system to become unstable! If this

happens, revert to the default setting.

GPU Boost [Keep Current Settings]

Allows you to enable the GPU Boost to accelerate the integrated GPU for extreme graphics

performance. Conguration options: [Keep Current Settings] [Enabled]

DRAM Timing Control

The subitems in this menu allow you to set the DRAM timing control features. Use the

<+> and <‑> keys to adjust the value. To restore the default setting, type [auto] using the

keyboard and press the <Enter> key.

Changing the values in this menu may cause the system to become unstable! If this

happens, revert to the default settings.
