1-4
Chapter 1: Product introduction
1.3 Central Processing Unit (CPU)
ThemotherboardcomeswithanonboardIntel
®
Celeron™QuadCore/DualCoreProcessor
andaspeciallydesignedCPUheatsink.
Channel Sockets
ChannelA DIMM_A1
ChannelB DIMM_B1
1.4.2 Memory configurations
Youmayinstall1GB,2GB,4GB,and8GBunbufferednon-ECCDDR3DIMMsintotheDIMM
sockets.
• YoumayinstallvaryingmemorysizesinChannelAandChannelB.Thesystem
mapsthetotalsizeofthelower-sizedchannelforthedual-channelconguration.Any
excessmemoryfromthehigher-sizedchannelisthenmappedforsingle-channel
operation.
• AlwaysinstallDIMMswiththesameCASlatency.Foroptimalcompatibility,we
recommendthatyouinstallmemorymodulesofthesameversionordatecode(D/C)
fromthesamevendor.Checkwiththeretailertogetthecorrectmemorymodules.
N3150M-EwithIntelSOCN3150.N3050M-EwithIntelSOCN3050
1.4 System memory
1.4.1 Overview
ThismotherboardcomeswithtwoDoubleDataRate3(DDR3)DualInlineMemoryModules
(DIMM)sockets.
ADDR3modulehasthesamephysicaldimensionsasaDDR2DIMMbutisnotched
differentlytopreventinstallationonaDDR2DIMMsocket.DDR3modulesaredevelopedfor
better performance with less power consumption.
N3150M-E
N3050M-E
N3150M-E / N3050M-E CPU
Intel SOC
N3150M-E
N3050M-E
N3150M-E / N3050M-E 240-pin DDR3 DIMM sockets
DIMM_A1
DIMM_B1
Attention: If only one
DDR3/-L memory module is
to be installed, be sure to
install it in DIMM_A1.
