Asus rog maximus viii extreme/assembly [13/226] Maximus viii extreme assembly specifications summary

xiii

(continued on the next page)

Internal I/O Ports

2 x USB 3.0 connector supports additional 4 USB 3.0 ports

3 x USB 2.0 connectors support additional 6 USB 2.0 ports [one

connector via ROG_EXT header]

2 x SATA Express connectors (compatible with 4 SATA 6Gb/s ports)

4 x SATA 6Gb/s connectors (2 x [gray]; 2 x [black])

1 x U.2 port

1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage

devices support

1 x ROG extension (ROG_EXT) header

1 x 4-Pin CPU fan connector

1 x 4-Pin CPU OPT fan connector

4 x 4-Pin Chassis fan connectors

1 x 4-pin Water pump connector

1 x 5-pin EXT_FAN(Extension Fan) connector

3 x Thermal sensor connectors

1 x 24-pin EATX power connector

1 x 8-pin EATX 12V power connector

1 x 4-pin EATX 12V power connector

1 x EZ Plug connector

9 x ProbeIt Measurement Points

1 x Power-on button

1 x Reset button

1 x Safe Boot button

1 x ReTry button

1 x LN2 Mode jumper

1 x Slow mode switch

1 x Memory switch header

1 x Front panel audio connector (AAFP)

1 x System panel connector

1 x MemOK! Button

1 x BIOS Switch button

1 x SLI/CFX switch (2/3/4-WAY adjustments)

1 x Thunderbolt header

MAXIMUS VIII EXTREME/ASSEMBLY specifications

summary
