Asus Xonar DG [7/58] Introduction
![Asus Xonar DG [7/58] Introduction](/views2/1163302/page7/bg7.png)
1ASUS Xonar DG
1. Introduction
1.1 Package contents
• ASUS Xonar DG PCI audio card
• Low Prole Bracket x1
• Support CD x1
• Quick Start Guide x1
1.2 System requirements
• One PCI 2.2 (or higher) compatible slot for the audio card
• Microsoft
®
Windows
®
7 (32/64bit) / Vista (32/64bit) / XP (32/64bit) / MCE2005
• Intel
®
Pentium
®
4 1.4 GHz or AMD
®
Athlon 1400 CPU or faster CPU
• 256 MB (or above) DRAM system memory
• 60 MB available HDD space for driver installation package
• CD-ROM drive (or DVD-ROM drive ) for software installation
• High-quality headphones or powered analog speakers to enjoy the ultra-high
delity sound of the card
