Arctic accelero s3 [2/8] Choose the correct mounting hole size and spacers

R7 260 (X*), Radeon HD 8760*, 8740,

7790*, 7770* (Ghz*), 7750, 7730, 6770*, 5770*

250(X), 240,

Radeon HD 6750, 6670 (LP), 6570, 5750, 5670,

5550 (OEM), 4770, 4730, 4670, 4650, 4550, 4350 (LP),

3650, 3470, 3450, 2600 (XT, Pro), 2400 (XT,Pro),

X1650 (XT,Pro), X1550, X1300 (XT, Pro)

R9 280**, R9 270**(X)**, R7 265**, Radeon 8870**,

7870** (GHz**, XT**), 7850*, 6950**, 6850*, 6870**,

6790**, 5850**, 5830**, 4890**, 4870**, 4850*, 4830*,

3870*, 3850, 3690, X1800 (XL,GTO,XT*),

X1900 (XT*, XTX*, GT*), X1950 (Pro*,GT*,XT*,XTX*)

GeForce GTS 450*, 250**, 240 (OEM)*, GT 340, 330,

320

GeForce GTX 560**(Ti**, SE**), 550 Ti*, 465**,

460**(SE**)

Please ensure your graphics card does not come with a stacked power socket.

*Recommended with properly ventilated case only

**Use with S3 Turbo Module only

Note: This table is for reference only. Please refer to your actual Graphics

card holes position during installation.

Updated information is available at support.arctic.ac/S3

Choose the Correct Mounting Hole Size and Spacers

If your VGA card is using the 1 43.2 x 43.2 mm mounting hole

If X > 25 mm, use mounting clip in Orientation A.

If X < 25 mm, use mounting clip in Orientation B.

Measure the distance between the bottom mounting hole and the edge

of the card.

Measure the distance between the bottom mounting hole and the edge

of the card.

Orientation A Orientation B

GeForce GTX 960, 760**, 680**, 670**,

660 Ti**, 660, 650 Ti boost**

GeForce GTX 750, 750Ti, 650, GT 640

GeForce GTX 650Ti*, GT 740*, 240, 220
