The GP8502P is an indoor optical network terminal designed for home users and small office and home office (SOHO)

users, providing one GPON port, one RJ11 phone port and two auto-negotiation & auto-MDI/MDIX Fast Ethernet ports.

By using the Gigabit-capable Passive Optical Network (GPON) technology, the GP8502P provides a high-speed data

channel through a single optical fiber with an upstream rate of 1.25Gbps and a downstream rate of 2.5Gbps. In this

way, you can enjoy the high-speed dataservice, quality voice service, superior video service.

Features:

2 Ports Fast Ethernet Plus

1 POTS GPON Terminal

GP8502P

Brief:

2 Ports Fast Ethernet Plus 1 POTS GPON Terminal

Easy Network, Trustable

GP8502P

> Complies with ITU-T G.984.2 CLASS B+

> Up to 1.25Gbps for upstream and 2.5Gbps for downstream speed

> Maximum transfer distance up to 20Km

> Supports SIP and H.248 voice protocol

> Multiple traffic mapping modes supported

> IGMP V2&V3 Snooping, IGMP proxy

> Supports VLAN filtering & VLAN transparent transmission, VLAN N:1 aggregation and VLAN 1:1 translation

> Local management through Web-based GUI and efficient remote management function

> 1* SC/APC GPON port, 1* RJ11 phone port, 2* 10/100Mbps auto-negotiation and auto-MDI/MDIX RJ45 LAN port

Others

Environment

Package

1 * GP8502P 1* 12V/1A Power Adapter 1 * Ethernet Cable

1 * RJ11 Phone Cable 1 * Quick Installation Guide

Operating Temperature: 0℃ ~40℃(32℉~104℉) Storage Temperature: -40℃~70℃(-40℉~158℉)

Operating Humidity: 5%~90% non-condensing Storage Humidity: 5%~95% non-condensing

Specification:

PWR,LOS,PON,LAN1, LAN2, PHONE

LED

1* SC/APC GPON port

1* RJ11 Phone port

2* 10/100Mbps Auto-negotiation and MDI/MDIX RJ45 LAN port

Hardware

Interface

Data Rate

Distance

Center Wavelength

Upstream 1.25Gbps Downstream 2.5Gbps

0-20KM

Tx: 1310 nmRx: 1490 nm

Extinction Ratio

>10 dB

Receive Sensitive

-27dBm

ITU-T G.984.2 CLASS B+ IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.1p, IEEE 802.1q

Software

Standard

GPON

GEM encapsulation mode

8 T-CONTs with up to 32 GEM ports

GEM port to T-CONT mapping

Multiple traffic mapping modes:

–Mapping from VLAN to GEM port

–Mapping from PRI to GEM port

–Mapping from Ethernet port to GEM port

–Mapping from VLAN+PRI to GEM port

–Mapping from Ethernet port+VLAN to GEM port

–Mapping from Ethernet port+PRI to GEM port

–Mapping from Ethernet port+VLAN+PRI to GEM port

–Mapping from IPToS to GEM port

Dynamic Bandwidth Assignment (DBA)

Forward error correction (FEC) function in the upstream and downstream directions

Embedded OAM, physical layer OAM (PLOAM), and OMCI

128-bit advanced encryption standard (AES) in the downstream direction

Authentication modes of SN, password, and SN+password

Deactivation/Activation and re-register of the ONT

Loopback test based on the GEM port

Optical Power

Tx optical power: 0.5~5.0dBm

Maximum overload optical power: -8 dBm

Button

Power ON/OFF, Default

Power Adapter

DC 12V/1A

Power consumption

<12W (MAX)

Dimensions (L x W x H ) 145x90 x28 mm

Multicast

IGMP V2&V3 Snooping

IGMP proxy

Bridge WAN multicast

Up to 255 multicast groups

VLAN transforming of the upstream multicast protocol packet

Separate GEM ports for the downstream multicast service streams and the IGMP signaling packets

Transformation, transparent transmission, and removal of the downstream multicast VLAN

Filtering downstream multicast packets

Multicast filtering and forwarding based on MAC address

Authentication based on the GEM port

Fast leave

Bridge Mode

Setting to 10/100Mbit/s manually

Setting to half duplex or full duplex mode manually

Upstream and downstream rate limit based on the Ethernet port with a granularity of 64kbit/s

PAUSE traffic control (IEEE 802.3 Annex 31B)

Ethernet frame of up to 2000 bytes

VLAN filtering and VLAN transparent transmission.

VLAN N:1 aggregation and VLAN 1:1 translation.

IEEE 802.1p Priority Queue

Ethernet

Optical power monitoring.

Local service configuration, query, and software upgrade on the Web page

Remote management using standard compliant OMCIinterface as defined byITU-T G.988

Query of the information about the ONT optical transceiver

Reporting the Dying Gasp alarm when the ONT is powered off

Maintenance

OMCI

OMCI configuration management (including the GEM port, T-CONT, CAR, and VLANconfigurations)

OMCI query management (including the device information and Ethernet port status)

OMCI alarming and alarm synchronization

OMCI performance statistics

MAC address filteringSecurity

Specifications are subject to change without notice. Netisis a registered trademark of Netis Systems Co., Ltd. Other brands and product names are trademarks or

registered trademarks of their respective holders. No part of the specifications maybe reproduced in any form or by any means or used to make any derivative such

as translation, transformation, or adaptation without permission fromNetis Systems Co., Ltd.

2 Ports Fast Ethernet Plus 1 POTS GPON Terminal

GP8502P

Topological Graph:

Internet

POS

2 Ports Fast Ethernet Plus 1 POTS GPON Terminal

GP8502P

AD1102

AD1103
