Brief:
The netis router MW5230 provides different ways for Internet access. It supports to connect with 3G/4G USB
modem for network sharing. Also you may try the traditional way to connect Ethernet cable to the WAN port or use
the wireless access(WISP) for Internet; then you may connect a USB storage device to the USB2.0 to share files,
stream media and setup a ftp server. For local connection, MW5230 provides the wireless transfer speed up to
300Mbps, ideal for faster downloading, Internet calling and HD video streaming.
MW5230
Easy Network, Trustable
Features:
>Compatible with 3G/4G USB Modems for network sharing
>Supports 3G/4G, DHCP, Static IP, PPPoE, PPTP, L2TP
>Incredible wireless high speed up to 300Mbps, great for faster downloading, Internet calling and HD video streaming
>MIMO high gain 5dBi antennas providing maximum range and stable connections
>Dual operation modes- Router, Bridge (pure access point)
>Multiple wireless modes- AP, Repeater, AP+WDS, WDS, Client
>Multi-SSID providing up to 3 additional separate networks for guests and friends
>Advanced VLAN function enables you to enjoy IPTV applications from ISP
>Easy wireless security setup at a push of the WPS button
>Alternative USB Functions for Storage Sharing, FTP Server and Media Server
Specification:
64/128-bit WEP WPA-PSK/WPA2-PSK(TKIP/AES)
SSID Broadcast Enable/Disable Wireless MAC Filtering
Wireless Security
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wireless
Standards
Signal Rate
Frequency Range
Transmit Power
Up to 300Mbps
2.4-2.4835GHz
20dBm(MAX)
Data Transfer Rate
Wireless Modes
AP, Repeater, AP+WDS, WDS, Client, Multi-SSID
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Hardware
Standards
Interfaces
LED Indicators
Buttons
1 * 10/100MbpsWAN port 4 * 10/100MbpsLAN port
1 * USB 2.0 Port, for 3G/4G USB Modem or USB Storage Device
WPS, USB, WAN, LAN1-LAN4, WLAN, PWR
WPS/Default
DC 12V/1A (Output)
Power Supply
VPN Pass-through
3G/4G, DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access, WISP
FCC, CE
Software
WAN Type
Certification
Port Forwarding
QoS
Access Control
Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port
WMM, Bandwidth Control
IP/MAC/Domain Filtering
Support Samba(Storage)/FTP Server/Media Server
PPTP, L2TP, IPSec
USB Sharing
Others
Environment
Package
1* Mw5230 1* 12V/1A Power Adapter
1* Ethernet Cable 1 * Quick Installation Guide(Multilingual)
Specifications are subject to change without notice. Netisis a registered trademark of Netis Systems Co., Ltd. Other brands and product names are trademarks or
registered trademarks of their respective holders. No part of the specifications maybe reproduced in any form or by any means or used to make any derivative such
as translation, transformation, or adaptation without permission fromNetis Systems Co., Ltd.
MW5230
3G/4G Wireless N 300Mbps Router
Antennas
3* 5dBi Fixed Antenna
Topological Graph:
802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)
20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g:(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)
Operating Temperature: 0℃~40℃Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
>Intelligent bandwidth control to manage the bandwidth usage for each computer reasonably
3G/4G Wireless N
300Mbps Router
>Internet Access Control- IP Filtering, MAC Filtering, Domain Filtering based on time
>Quick setup, with built-in multilingual management page
IPTV, Dynamic DNS, Static Routing, WOL, Backup & Restore, Firmware Upgrade
Others
3G/4G Internet
Laptop
Smart Phone
3G/4G Wireless N 300Mbps Router
MW5230
Application 1: 3G/4G Access
Wired
Wireless
3G/4G USB Modem
Application 2: WAN Access
Internet
Laptop
USB Storage Drive
3G/4G Wireless N
300Mbps Router
MW5230
{
Storage Sharing
FTP Server
Media Server
Mbps
300
Multi SSID
Repeater
WPS
WISP
5dBi
Dual Access
Easy Setup
QoS
WDS
Bridge
WANWAN
LANLAN
IPTV
USB 2.0
3G/4G
G
