Braun 730/SI 17780 [10/79] D textile protector

The Precision Shot function can also be

used in the vertical position for steaming

hanging clothes.

Caution: Hot steam comes out from the

preconditioning nozzles.

Spray function

Press the spray button (5).

Dry ironing

Set the steam regulator (6) on position «0»

(= steam off).

D Textile Protector

(730 model only)

Before attaching the Textile Protector (10)

for the first time, iron approximately 2

minutes without Textile Protector. The

Braun Textile Protector protects delicate

fabrics from heat damage and makes it

possible to iron most dark fabrics without

an intermediate cloth.

A special coating avoids shiny patches.

However, in order not to damage the

coating, avoid ironing over e.g. zippers,

metal buttons/rivets or strass with the

Textile Protector attached.

To check the reaction of your fabrics

before you start ironing, we recommend

that you iron a small section of material on

the reverse side. With the Protector, you

are able to iron delicate fabrics with the

temperature setting within the solid red

range so that you can use all steam

functions your iron offers.

After having attached the Textile

Protector, wait about 1 1/2 minutes before

you start ironing. Always store your iron

with the Textile Protector detached.

E After ironing

Unplug the iron and turn the steam

regulator to position «0». To prolong the

life of the iron, empty the water tank.

Store the cool iron in a dry place always

standing on its heel rest.

F Maintenance and cleaning

To clean the sole plate, use steel wool.

Never use a scouring pad, vinegar or other

chemicals.

G Cleaning the anticalc valve

The anticalc valve located on the lower

end of the steam regulator has to be

decalcified regularly (e.g. whenever steam

development is insufficient). For this, the

water tank has to be empty.

Removing the steam regulator with the

anticalc valve

Turn the steam regulator clockwise

towards the steam setting «6». Keep

on turning firmly beyond the resistance

until the steam regulator is lifted. When

positioned at

, pull it out vertically.

Do not touch the anticalc valve at its lower

end. Immerse the anticalc valve in vinegar

(not vinegar essence) or lemon juice for

a minimum of 30 minutes. Brush off

remaining residues and rinse under

running water (fig. G, 1-7).

Re-inserting the steam regulator

When re-inserting the steam regulator,

make sure the steam regulator base still

points on setting

(fig. G 8). Firmly push

down the steam regulator until it turns

back to setting «6» (fig. G) where it

catches.

Notice: The iron must never be used

without steam regulator.

H Decalcifying/anticalc system

In order to clean the steam chamber from

residues, decalcify it as shown in picture

section H, 1-8.

Caution: Hot water and steam will come

out from the sole plate when the steam

regulator is turned clockwise beyond

setting «6».

Wait for the sole plate to cool down, then

clean it as described above. Then refill the

tank with water, heat up the iron and press

the precision shot button 4 times to rinse

the iron before ironing (fig. H, 9-13).

Do not use commercial decalcifiers, they

may damage the iron.

Trouble-shooting guide

Problem Remedy

Drops coming

out of the steam

vents.

Turn the steam

regulator anti-clock-

wise to reduce the

steam or turn it off.

Take longer intervals

when pressing the

Precision Shot button.

Select a higher

temperature setting.

Less steam

develops or no

steam at all.

Check water level.

Clean the anticalc

valve.

Calcium particles

coming through

the steam vents.

Decalcify the steam

chamber.

92263375_TS_730_S06-80 Seite 10 Freitag, 23. März 2012 12:58 12
