300Mbps Wireless-N Broadband Router Quick Installation Guide

Method 2: PIN

 Select this router for connection in your OS network connections or wireless adapter

software settings

 Choose to enter the WPS PIN of the router and provide default router WPS PIN

printed on label on bottom of router. This PIN may be changed though, and you may

do so/confirm current PIN in the router's user interface – click „Wireless

Management‟- „AP Setup‟ - „WPS‟ and you will be able to see the AP PIN as well as

generate a new one and save it

 Alternatively, you may choose to utilize a WPS PIN provided by your wireless

adapter and enter it in the router in the same part of the user interface - click „Wireless

Management‟- „AP Setup‟ - „WPS‟ and enter adapter PIN for „Wireless Host PIN

Code‟.

7.2.5. WDS (Wireless Distribution System)

If you are using this router to spread the wireless coverage of another router, or to spread the

coverage to another router, you can use WDS. For this example, WDS will be established

between a router that the MAC address is 00-22-4f-cc-ae-f5 (R1) and another router that the

MAC address is 00-22-4f-bc-af-5d (R2). The MAC address is printed on a label on the bottom

of the router, or may be seem both netis routers. Please follow the steps below, but keep in

mind that if one router in this setup is not netis you should first confirm it is capable of WDS

and its interface menu may be considerably different:

R1:

 It should first be established that routers function normally as a routers not in a network

involving WDS, and R1 (the router connected to a modem) should be configured below from a

starting point where it was individually functional.

 Click on „Wireless Management‟- „AP Setup‟- „Security‟ and select and save None as

authentication type

 Click on „Wireless Management‟- „AP Setup‟- „Basic‟ and select and save radio mode as

WDS or AP + WDS

 Click on „Wireless Management‟- „AP Setup‟- „Security‟ and select and save None as

WDS authentication type or select a WDS security type, enter key and save. Note that some

other brands of router may not have the option of or be compatible in WDS wireless security.

For key parameters, please refer to Wireless security settings
