Netis WF-2404 WF-2404D [4/13] Configure your computer

300Mbps Wireless-N Broadband Router Quick Installation Guide

WPS

Flashing slowly

WPS is running

SYS

Flashing

Normal

WLAN

Flashing

Wireless data transmitting

WAN

WAN Connection normal

Flashing

Data transmitting

LAN

Corresponding LAN port connection normal

Flashing

Corresponding LAN port data transmitting

5. Configure Your Computer

You can manage the 300Mbps Wireless-N Broadband Router through the Web browser- based

configuration utility. To configure the device via Web browser, at least one properly

configured computer must be connected to the device via Ethernet or wireless network. The

Router is configured with the default IP address of 192.168.1.1 and subnet mask of

255.255.255.0 and its DHCP server is enabled by default.

Here we use Windows XP for example. If your network settings are not already set and

you need to complete this step, the configurations are similar for the other operating

systems.

 Open My Computer on your desktop or through the Start menu, right click on My

Network Places in the Other Places menu to the left and select Properties. Right click

on your Local Area Connection in the window that appears and select Properties. In the

properties window that appears, under “This connection uses the following items:” select

Internet Protocol (TCP/IP) and then click the Properties button below.
