Datasheet:UPS-LGR-0001/GB Update:01/09/2012
1. GENERAL FEATURES (continued)
3 103 50
MegaLine 1250
01/09/2012
2/2
Output
• Voltage
• Frequency
• N+Xredundancy
Input
• Enablesynchronisation
• Extendedsynchronisation
interval
By-Pass
• Enable
• Forced
• Operationsensitivity
• Off-linemode
• Loadwaitingmode
Neutral sensor
• Enable
• Ignoreduringoperation
Batteries
• Capacity
• Thresholds
• Max.durationperbattery
• Max.durationperbattery
after the reserve capacity
threshold
• Enablebatterytest
• Enableauto-restart
The UPS also allows the following adjustments to be made through the
display:
The Static MegaLine UPS has the CE marking, pursuant
toDirectives73/23,93/68,89/336,92/31,93/68andisdesigned
and built in compliance with the following standards:
• EN62040-1“GeneralandsafetyrequirementsforUPSused
in operator access areas”
• EN62040-2“Electromagneticcompatibility(EMC)requirements”
• EN62040-3“Methodofspecifyingtheperformanceandtest
requirements”
Manufacturing specifications
Maximum weight
23.5 kg
(for a back-up time of 11’ – 80% of the load)
Maximum dimensions (W×L×H)
270×570×475 mm
(for a back-up time of 11’ – 80% of the load)
Type of switching High frequency PWM
Rectifier/booster/invertertechnology MOSFET
Interfaces
1×serial port RS232 +
2×Logic Contact ports
Noise level measured at 1 meter <40dBA
Degree of protection IP21
Installed power boards 1
Free power expansion slots 3
Installed battery kits 1
Free uptime expansion slots 3
Battery features
Type of battery Lead-acid, sealed, maintenance-free
Unitary capacity 9Ah(12V)
UPSbattery/batterymodulevoltage 36 V max. (series of 3*12V)
Batterymoduleprotection 2 fuses for each battery module
Output features (battery operation)
Rated output voltage 230 V (adjustable by 1 V intervals)
Tolerance on the output voltage
Static ± 1%;
Dynamic (0-100%; 100-0%) ± 1%
Output frequency 50 Hz or 60 Hz ± 1%
Rated/activeoutputpower 1,250VA/875W
Total harmonic distortion of the output voltage
on non-linear rated load, P.F.=0.7
< 1 %
Overload capacity:
•for15seconds
160%
Input features
Rated input voltage 230 V
Input voltage interval From 184 V to 264 V with rated load
Minimum voltage in network operation 100 V at 50% of the load
Input frequency
50 Hz or 60Hz
(autosensing or selected by the user)
Total harmonic distortion of the input current
(THDI
in
)
< 3% at 100% of the rated load
Power factor >0.99from20%to100%oftheratedload
Inrush current At most 100% of the load current
Output features (network operation)
Rated output voltage 230 V (adjustable by 1 V intervals)
Rated/activeoutputpower 1,250VA/875W
Tolerance on the output voltage
Static ± 1%;
Dynamic (0-200%; 200-0%) ± 1%
Total harmonic distortion of the output voltage
Linear load < 0.5 %;
Non-linear load < 1 %
Rated output frequency
50 Hz or 60 Hz
(autosensingand/orselectedbytheuser)
Tolerance on the output frequency
Synchronised to the input frequency;
± 1% when not synch.
Crest factor on the output current 3.5:1
Overload capacity:
•foratleast1second
•foratleast5seconds
•foratleast30seconds
300% without the operation of the automatic bypass
200% without the operation of the automatic bypass
150% without the operation of the automatic bypass
2. TECHNICAL FEATURES
General Features
Type of operation On line double conversion
UPS Structure
Modular, Expandable, N+X Redundant
with modules having a power from 1,250VA,
contained in a single cabinet
Neutral Connectivity Solid neutral
Wave shape in networked operation Sinusoidal
Wave shape in battery operation Sinusoidal
Type of bypass Static and electromechanical
Switching time None
