CSB gp 1245 Инструкция по эксплуатации онлайн

Cells Per Unit 6

Voltage Per Unit 12

Capacity 4.5Ah @ 20hr-rate to 1.75V per cell

Weight Approx. 1.66 kg(3.66 lbs)

Maximum Discharge Current 60A/90A(5sec)

Internal Resistance Approx. 40.5 mΩ

Operating Temperature Range

Nominal Operating Temperature Range

Float Charging Voltage

Recommended Maximum Charging 1.35A

Current Limit

Equalization and Cycle Service

Self Discharge CSB Batteries can be stored for more than 6 months at

Please charge batteries before using. For

higher temperatures the time interval will be shorter.

Terminal F1/F2-Faston Tab187/250

Container Material ABS(UL 94-HB) & Flammability resistance of

(UL 94-V0) can be available upon request.

Discharge:

Charge:

Storage:

Constant Power Discharge Characteristics Unit:W (25°C,77°F)

Constant Current Discharge Characteristics Unit:A (25°C,77°F)

GP 1245

12V 4.5Ah

Specification

GP 1245 is a general purpose battery up to 5 years in standby

service or more than 260 cycles at 100% discharge in cycle

service. As with all CSB batteries, all are rechargeable, highly

efficient, leak proof and maintenance free.

Width (W)

Dimensions :

Unit: mm (inch)

Overall Height (H) Container height (h) Length (L)

108±1.5 (4.25±0.06) 102±1.5 (4.02±0.06) 92.8±1 (3.65±0.04) 69.9±1 (2.75±0.04)

13.5 to 13.8 VDC/unit Average at

14.4 to 15.0 VDC/unit Average at

(http://www.csb-battery.com)

by TUV CERT according to ISO 9001,ISO 14001.

The system of manufacturer was certified

F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR

1.60V

18.7 12.3 9.08 5.37 3.11 2.26 1.80 1.26 0.81 0.53 0.43 0.23

1.67V

17.6 11.8 8.88 5.31 3.09 2.25 1.79 1.24 0.80 0.53 0.43 0.23

1.70V

17.0 11.6 8.79 5.28 3.08 2.23 1.78 1.24 0.80 0.53 0.43 0.23

1.75V

16.1 11.2 8.62 5.21 3.06 2.22 1.77 1.23 0.80 0.53 0.43 0.22

1.80V

15.0 10.7 8.42 5.13 3.03 2.21 1.76 1.22 0.80 0.52 0.43 0.22

1.85V

13.8 10.3 8.21 5.04 3.00 2.18 1.74 1.21 0.79 0.52 0.42 0.22

F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR

1.60V

221 145 110 65.9 38.6 27.9 22.2 16.1 10.7 7.09 5.79 3.19

1.67V

206 139 107 65.4 38.4 27.7 22.0 16.0 10.6 7.08 5.78 3.17

1.70V

199 137 105 64.9 38.1 27.6 21.9 15.9 10.5 7.04 5.76 3.16

1.75V

188 133 102 64.7 38.0 27.5 21.8 15.8 10.4 7.02 5.74 3.16

1.80V

177 128 100 63.6 37.7 27.2 21.5 15.7 10.3 6.96 5.71 3.13

1.85V

165 122 96.6 60.9 36.7 26.7 21.3 15.5 10.2 6.89 5.63 3.09

@25°C (77°F)

25°C (77°F)

-15°C~50°C ( 5°F~122°F)

-15°C~40°C ( 5°F~104°F)

25°C (77°F).

25°C±3°C (77°F±5°F)

RA1406

Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.

TUV Asia Pacific Ltd.

Taiwan Branch

TUV Asia Pacific Ltd.

Taiwan Branch

CSB-manufactured VRLA

(Absorbent Glass Mat type)

batteries are UL-recognized

components under UL1989.

CSB is also certified by

ISO 9001 and ISO 14001.
