87045 LIMOGES Cedex
Phone number : (+33) 05 55 06 87 87 - Fax : (+33) 05 55 06 88 88
INDEX Page
1. General specifications ...........................1
2. Technical specifications ......................... 2
3 104 63
ARCHIMOD HE 100 kVA
The Legrand ARCHIMOD HE, model 100, is an UPS on line double
conversion with PWM Hi-Frequency technology. It has passing trough
neutral and Modular Architecture with the possibility to have N+X
redundancy. The nominal power is 100 kVA – 100 kW. Batteries are
lead acid, sealed, free maintenance, valve regulated, and arranged,
inside the UPS or external battery cabinet, in dedicated Drawers, in
order to guarantee compact dimensions reducing weights and DC
voltage level.
1.1 Modularity
The UPS ARCHIMOD HE 100 has modular architecture, it is
composed by identical modules which work in parallel. Modules are:
• PowerModules6,7kVA;
• BatteryDrawersofsevenbatteries(9Ah),indedicatedcabinet.
These modules are installed inside the UPS and have identical
functions.
Power Modules are composed by the following circuits:
• Rectifier/PFC
• Inverter
• BatteryCharger
• CommandLogiccircuit
• AutomaticBy-pass
Battery drawers contain 7 batteries, and are easy to be move and
replace.
1.2 Scalability
ThemodularityofARCHIMODUPSallowstoexecutePowerand
Autonomy upgrade. Thanks to the intelligent Plug N’ Play connection,
no HW and SW settings are needed to increase or decrease the
power or the autonomy.
1.3 Redundancy
The modularity of the UPS allows the N+X redundant configurations.
TheRedundancyisachievedusingmoremodulesthanneeded,
modules will run in “load sharing”.
1.4 Architecture
The UPS ARCHIMOD HE 100 is three–phase input and output, the
architecture is distributed parallel architecture in each phase (there
are more modules in the same phase).
In case of redundant configuration, whenever one module fails, the
other modules in the same phase will guarantee the energy supply
and protection to the load. The available power in each phase will be
always the sum of the power of the modules installed in that phase.
1.5 Hot-plug
The UPS ARCHIMOD HE 100 The power modules are independently
controlled by 3 Command Tunnel. Each Command Tunnel controls three
(or six) power modules. It is possible to turn off only one command
tunnel and install or replace modules inside of it, when the other tunnel
1. GENERAL SPECIFICATIONS
is still running. This allows the service on a part of the UPS without
turn off the complete system, losing only the power of the tunnel in
maintenance. In case of redundancy or scalability, the load is protected
by the UPS also during the replace or upgrade of power modules.
1.6 By-pass
In each Power Module there is a static By-pass system which, in case of
overload or other anomaly, automatically transfer the load to the mains.
The UPS has embedded the manual bypass for service and maintenance
and it is possible to connect a dedicated bypass input line.
A dedicated software of remote monitoring and management, installed
on a PC connected to the UPS, allows to check and set all working
parameters of ARCHIMOD HE (the same functions available on
the UPS control panel) and, furthermore, to schedule and program
computer remote shutdown.
Optional software (UPS SuperviSor) or Net Interface card (CS121 SK)
allow the multi server shutdown and UPS remote control on the LAN.
ARCHIMOD HE is controlled by a main microprocessor which works
togetherwithmicroprocessorsineachpowermodules;Bydisplayis
possible to check all measurements, working parameters and status of the
system.
Here follow the measurements and working parameters available on the
display:
Technicalsheet:UPS-LGR-0074/GB 01/02/2014Lastupdate:01/02/2014
1/2
Input
Current:
• RMSvalue
• Peakvalue
• CrestFactor
Voltage:
• Ph-NRMSvalue
• Ph-PhRMSvalue
• BypassLineVoltage
Power:
• Nominal(VA)
• Active(W)
Power Factor
Frequency
Output
Current:
• RMSvalue
• Peakvalue
• CrestFactor
Voltage:
• Ph-NRMSvalue
• Ph-PhRMSvalue
Power:
• Nominal(VA)
• Active(W)
Power Factor
Frequency
Batteries
• Voltage
• Capacity
• Current
• Historydata
• ResidualCapacity
• Chargingstatus
Misc.
• InternalTemperature
• FanSpeed
• HVDCBUSVoltage
DATA LOG.
• By-passintervention
• Overheats
• Overloads
• Batteryinterventions
• Totaldischarge
• Events(info,warning,critical)
• Alarms
