Technicalsheet:UPS-LGR-0074/GB Lastupdate:01/02/2014
3 104 63
ARCHIMOD HE 100 kVA
01/02/2014
2/2
1. GENERAL SPECIFICATIONS (continue)
Output
• Voltage
• Frequency
• Phasesconfiguration
Input
• Enablefreq.synchronizing
(PLL)
• Extendedsynchronizingrange
(Extended PLL)
BY-PASS
• Enabling
• Forced
• DIPSpeed
• ECOMode
Batteries
• StartuponBattery
• Thresholdvalue
• Autorestart
• MaxTimeonbattery
The UPS allows also the following settings by display:
The UPS ARCHIMOD HE has the CE Mark accordingly with the EU
Directives2006/95,2004/108anditcomplywithfollowingstandards:
• EN62040-1“Generalrulesforelectricsafety”
• EN62040-2“Electromagneticcompatibilityandimmunity(EMC)”
• EN62040-3“Performancesandtestingrules”
2. TECHNICAL SPECIFICATIONS
General Specifications
UPS Topology On line double conversion VFI SS 111
Architecture of the UPS
Modular, scalable, redundant based on 6.7kVA
Power Modules
In/OutphaseConfiguration Three phase-Three phase
Neutral Neutral Passing through
Output wave form on mains run Sinusoidal
Output wave form on battery run Sinusoidal
Bypass type Static, electro-mechanic and maintenance bypass
Transfer time Zero
Input
Nominal Voltage 380, 400, 415 3ph+N+PE
Voltage range -20% +15%
Frequency
45-65Hz
(autosensing)
THDI
in
< 3%
Power Factor >0.99
Output with mains (AC-AC)
Nominal voltage 380, 400, 415 3ph+N+PE
Nominal power 100.000 VA
Active power 100.000 W
Efficiency (VFI) 96%
Voltage variation (static) ± 1%
Voltagevariation(dynamic0-100%;100-0%) ± 1%
THDv on nominal power (linear load) < 0,5 %
THDv on nominal power
(not linear load P.F.=1)
< 1 %
Frequency 50Hzo60Hz(autosensingorselectable)
Frequency tolerance
Synchronizedwithinputfrequencyor
± 1% free run
Current Crest Factor 3:1 accordingly with IEC 62040-3
Overload capability:
•10min
•60sec
115% load rate with no bypass intervention
135% load rate with no bypass intervention
Output in battery Run (DC-AC)
Nominal voltage 380, 400, 415 3ph+N+PE
Nominal power 100.000 VA
Active power 100.000 W
Voltage variation (static) ± 1%
Voltagevariation(dynamic0-100%;100-0%) ± 1%
THDv on nominal power (linear load) < 0,5 %
THDv on nominal power
(not linear load P.F.=1)
< 1 %
Frequency 50Hzo60Hz(autosensingorselectable)
Frequency tolerance ± 1% free run
Current Crest Factor 3:1 accordingly with IEC 62 040-3
Overload capability:
•10min
•60sec
115%
135%
Battery
Type LeadAcid,sealed,freemaintenanceVRLA
Unit Capacity 9Ah(12V)
Nominal UPS Battery Voltage 252 Volt DC
Battery charger type PWM hi efficiency, one in each power module
Charging Cycle
Smart Change technology
3-step advanced cycle
Max Charging Current 2,5 A each power module
Environmental specs
Noise level @ 1m 58 dBA
Working temperature range from 0°C to +40°C
Stock temperature range from -20°C to +50°C (excluded batteries)
Humidity range 0-95%notcondensing
Protection degree IP21
Mechanical an Miscellaneous
Net Weight without batteries
1
318 kg
Dimensions (WxHxD)
2
1x(570x2080x912)(mm)(onlyinverter)
Colour RAL7016
Technologyrectifier/booster/inverter MOSFET/IGBT
Communication Interface
(for each command tunnel)
2serialportRS232,1logiclevelport,5Dry
contacts port, 1 slot for SNMP optional interfaces
Input/Outputconnections 3Ph + N + PE
Number of Command Tunnels 3
Number of installable Power Modules 15 of 6700 VA
Standards EN 62040-1, EN 62040-2, EN 62040-3
1
The weigh depends by the number of the installed batteries accordingly with the required
autonomy.
2
The battery cabient dimension can change depending battery set accordingly with the
required autonomy.
