Control Panel

GL2 Settings

Setting Item Description, Instructions

Monochrome Print in monochrome.

Color (CAD) 1 * Print in standard colors.

Color (CAD) 2 Print in brighter colors.

Color (CAD) 3 Print emulating the Canon BJ-W3000/W3050, in colors

resembling colors produced by these printers.( *1 )

Color (CAD) 4 Print emulating the HP Designjet 500/800, in colors resembling

colors produced by these printers.( *1 )

Color (CAD) 5 Print emulating the HP Designjet 1000, in colors resembling

colors produced by this printer .( *1 )

Color Mode

Color (CAD) 6 Print emulating the HP Designjet 4000/4500, in colors

resembling colors produced by these printers.( *1 )

Print Quality Choose the print quality .

Print (Economy) Although printing quality is diminished, less ink is consumed

than in regular printing. Select On to conserve ink.

Input Resolution Choose the printer input resolution, 600dpi or 300dpi .

Paper Source Choose the source of paper for HP-GL/2 printing.

Conserve Paper Conserves paper when printing.

Line Cap Choose the shape of the end point, determined by Software

or Rounded .

• If you choose Software

Operation is determined by the application. If nothing is

specied by the application, the result is as shown in the

gure.

• If you choose Rounded

Smoothing Choose whether to print arcs as smooth curved lines or as

multiple connected line segments.

• If you choose Software

Operation is determined by the application. If nothing is

specied by the application, the result is as shown in the

gure.

Note: By default, this is a 72-sided gure
