Corsair carbide series air 540, cc-9011030-ww, w/o psu, black [7/14] Air 540 high airflow mid tower case
![Corsair carbide series air 540, cc-9011030-ww, w/o psu, black [7/14] Air 540 high airflow mid tower case](/views2/1165910/page7/bg7.png)
H
I
J
K
L
M
N
H
I
J
K
L
M
N
Built-in cable routing cutouts with grommets
Trous de câblage avec œillets
Integrierte gummiverkleidete Kabelführungsönungen
Fessure per la gestione dei cavi con passacavi
Aberturas troqueladas para cables integradas, con arandelas
Обрезиненные отверстия для прокладки кабелей
带护线环的内置电缆布线保险装置
組み込み型ケーブルルーティングカットアウト (グロメット搭載)
Tool-free optical drive bays (x2)
2 baies pour lecteurs optiques amovibles sans outil
(x2) Einschübe zum werkzeugfreien Einbau optischer Laufwerke
2 alloggiamenti per unità ottiche rimovibili senza viti
(x2) Bahías para unidades de disco óptico extraíbles sin
necesidad de herramientas
2 съемных отсека для установки приводов оптических дисков без инструментов
(2 个) 免工具式可移动光驱托架
工具不要のリムーバブル光ディスクドライブベイ (x2)
Tool-free 3.5" hard drive caddy with 2.5" compatibility (x2)
2 plateaux de disque dur de 3.5" avec installation sans outil, compatibles 2.5"
(x2) 3,5-Zoll-Laufwerkseinschübe mit 2,5-Zoll-Kompatibilität
2 supporti per disco rigido da 3.5" senza viti, compatibili con unità da 2.5"
(x2) Bandejas para discos duros de 3.5" sin necesidad de herramientas y
compatibles con unidades de 2.5"
2 отсека д ля жестких дисков 3.5" с поддержкой 2.5" и возможностью установки без инструментов
(2 个) 免工具式 3.5" 硬盘盒, 兼容 2.5"
工具不要の 3.5 インチハードドライブキャディ (2.5 インチ対応) (x2)
HDD/SDD Hot-swap bay (x2)
2 baies de disques durs/SDD échangeables à chaud
(x2) Hot-Swap-Laufwerkseinschub (Festplatten- oder SSD-Laufwerke)
2 alloggiamenti per sostituzione a caldo HDD/SDD
(x2) Bahía de disco duro/SSD intercambiable en caliente
2 отсека д ля горячей замены жестких дисков/SDD-накопителей
(2 个) HDD/SDD 热插拔托架
HDD/SDD ホットスワップベイ (x2)
Tool-Free expandable 2.5" SSD removable cage
Baie de disque SSD 2.5" extensible et amovible sans outil
Erweiterbare, abnehmbare 2,5-Zoll-SSD-Laufwerkshalterung
zum werkzeugfreien Einbau
Scomparto rimovibile per unità SSD da 2.5" espandibile e senza viti
Bandeja para SSD de 2.5" extraíble y ampliable sin necesidad de herramientas
Съемный держатель для 2.5" SSD-накопителей с возможностью расширения и установки без
инструментов
免工具式可扩展 2.5" SSD 可移动托盘
工具不要の拡張可能 2.5 インチ SSD リムーバブルケージ
Eight expansion slots for GPUs
8 slots d'extension pour les GPU
(x8) Erweiterungssteckplätze für GPUs
8 slot di espansione per GPU
(x8) Ranuras de expansión para GPU
Восемь слотов расширения aдля установки графических карт
(2 个) GPU 扩展槽
GPU 拡張スロット (x8)
Removable Front Magnetic low restriction dust filter
Filtre à poussière avant magnétique à faible restriction amovible
Abnehmbare Frontverkleidung mit magnetischem widerstandarmem Staubfilter
Filtro magnetico antipolvere anteriore, a bassa ostruzione e rimovibile
Filtro antipolvo magnético frontal y extraíble para espacios reducidos
Съемный магнитный передний пылевой фильтр с низким сопротивлением
可移除式前部磁性低限制灰尘过滤器
抵抗の少ない前面マグネット式リムーバブル防塵フィルタ
CARBIDE SERIES
®
AIR 540 HIGH AIRFLOW MID-TOWER CASE
06
