D-Link dph-150s/f4 [56/87] Audio configuration
![D-Link dph-150se/f4 [56/87] Audio configuration](/views2/1166102/page56/bg38.png)
AUDIO Configuration
Field name
explanation
First Codec
The first preferential DSP codec: G.711A/u, G.722,
G.723, G.729.
Second Codec
The second preferential DSP codec: G.711A/u, G.722,
G.723, G.729.
Third Codec
The third preferential DSP codec: G.711A/u, G.722,
G.723, G.729.
Fourth Codec
The forth preferential DSP codec: G.711A/u, G.722,
G.723, G.729.
Fifth Codec
The fifth preferential DSP codec: G.711A/u, G.722,
G.723, G.729.
Sixth codec
The sixth preferential DSP codec: G.711A/u, G.722,
G.723, G.729.
Handset Input
Volume
Specify Input (MIC) Volume grade.
G729AB Payload
Length
Set G729 Payload Length.
Onhook Time
Specify the least reflection time of Hand down, the
default is 200ms.
Default Ring Type
Select Ring Type.
Handset Output
Volume
Specify Output (receiver) Volume grade.
Speakerphone
volume
Specify Speakerphone Volume grade.
Ring Volume
Specify Ring Volume grade.
G722 Timestamps
160/20ms or 320/20ms is available.
G723.1 Bit Rate
5.3 kb/s or 6.3 kb/s is available.
Default Ring Type
Set up the ring by default.
Tone Standard
Select Tone Standard.
Enable VAD
Select it or not to enable or disable VAD. If enable
