DJI phantom 2 [4/36] In the box

In the Box

PHANTOM 2

Remote Control-2.4GHz

Propeller Pair

Intelligent Battery

Charger

Plug Set

Screwdriver

Assistant Wrench

Cables

Micro-USB Cable

Screws

Accessories Box

Legend

Forbidden(Important)

Caution

Tip

Reference
