Removing the Display Assembly | 41
4 Open the palm-rest assembly as far as possible to release the display hinge from
the palm-rest assembly.
5 Lift the palm-rest assembly away from the display assembly.
1 display hinge 2 display assembly
3 palm-rest assembly
1 palm-rest assembly
1
2
3
1
