![Dell p2415q [12/51] Electrical specifications](/views2/1166469/page12/bgc.png)
12 | About Your Monitor
Electrical Specifications
Video input signals •Digital video signal for each dierential line.
Per dierential line at 100 ohm impedance.
•DP 1.2/HDMI 1.4/MHL 2.0 signal input support
Synchronization input
signals
Separate horizontal and vertical synchronization,
polarity-free TTL level, SOG (Composite SYNC on green)
Input voltage/ frequency/
current
100-240 VAC / 50 or 60 Hz ± 3 Hz / 1.8 A (maximum)
Inrush current 120 V: 30 A (Max.)
240 V: 60 A (Max.)
Physical Characteristics
Model P2715Q P2415Q
Connector type •DP connector (include DP
in and DP out)
•mDP
•HDMI (MHL)
•Audio line-out
•USB 3.0
•DP connector (include DP
in and DP out)
•mDP
•HDMI (MHL)
•Audio line-out
•USB 3.0
Signal cable type • mDP to DP 1.8 M cable.
•USB 3.0 1.8 M cable.
• mDP to DP 1.8 M cable.
•USB 3.0 1.8 M cable.
Dimensions (with stand):
Height (extended) 538.86 mm (21.22 inches) 499.53 mm (19.67 inches)
Height (compressed) 423.86 mm (16.69 inches) 369.53 mm (14.55 inches)
Width 640.74 mm (25.23 inches) 566.64 mm (22.31 inches)
Depth 203.86 mm (8.03 inches) 205 mm (8.07 inches)
Dimensions (without stand):
Height 379.66 mm (14.95 inches) 336.06mm (13.23 inches)
Width 640.74 mm (25.23 inches) 566.64 mm (22.31 inches)
Depth 51.50 mm (2.03 inches) 46.93 mm (1.85 inches)
Stand dimensions:
Height (extended) 417.31 mm (16.41 inches) 400.50 mm (15.77 inches)
Height (compressed) 302.31 mm (11.90 inches) 270.50 mm (10.65 inches)
Width 245 mm (9.65 inches) 245 mm (9.65 inches)
Depth 203.86 mm (8.03 inches) 205 mm (8.07 inches)
Weight:
With packaging 10.66 kg (23.50 lb) 8.68 kg (19.14 lb)
