Ensto eco16fjw, для теплого пола [9/12] Technical data

the ON-position there is a leakage in the circuit. In that case the thermostat does not allow

switching on the current and the product is operating properly. A quali ed person must

always examine the reason of the leakage.

4. TECHNICAL DATA

The warranty period for ENSTO Eco thermostats is 2 years from the date of purchase but no

longer than 3 years from the date of manufacture. Warranty conditions, see www.ensto.com.

Operating voltage 230 V -15%, +10%, 50 Hz

Nominal current 16 A

Maximum power 3600 W

Nominal residual operating current 30 mA

RCD type A

Switch 2-pole

Operating temperature - 20...+30 °C

Thermostat adjustment range 10 - 60 degrees

Temperature reduction  xed – 4 °C, control 230V

Signal light

green: the thermostat is on and the heating is

o

red: the heating is on

Floor sensor

NTC, 47 kΩ/25 °C, cable 4 m (extendable to 10

Floor sensor resistance values table 1, (sensor not connected).
