Foxconn at-7700-0h0wbae [5/22] 1 front side view

2 3

INTRODUCTION INTRODUCTION

1 PowerbuttonwithPowerindicatorLED

PresstoturnyourNanoPConoroff,theLEDcanindicateyoursystem

states.

2 Speaker

USB3.0port

ThisUSBportsupportstheUSB3.0/2.0/1.0specication.Usethisportfor

USBdevicessuchaskeyboard,mouse,USBprinter,USBashdrivesand

harddiskdrives,etc.

AstoWindows7system,youneedtoinstalltheUSB3.0driverinNanoPC

USBDiskbeforeusingit.

Multi-Functioncardreader

ThismemorycardreadersupportsSD/SDHC/SDXC/MS/MSPro/MMC

memorycardsusedindeviceslikedigitalcameras,mobilephones,Media

players and so on.

Microphone/SPDIFinport

Connectstoamicrophoneorplaybackdeviceswithopticalconnectors

(3.5mmjack).

SPDIFfunctionrequiresadditionaladapterandadaptercable.

Headphone

Connectstoaheadphone.

7 Kensington lock

AttachaKensingtonsecuritysystemoracompatiblesecuritylocktosecure

yourNanoPCinplace.

1-1 Front Side View
