Содержание
- Copyright 3
- Disclaimer 3
- Identifying your motherboard revision 3
- Chapter 1 hardware installation 4
- Chapter 2 bios setup 3 4
- Chapter 3 drivers installation 0 chapter 4 appendix 0 4
- Ga 78lmt usb3 motherboard layout ga 78lmt usb3 motherboard block diagram 4
- Table of contents 4
- Box contents 5
- Ga 78lmt usb3 5
- Ga 78lmt usb3 motherboard 5
- Ga 78lmt usb3 motherboard layout 5
- I o shield 5
- Motherboard driver disk 5 two sata cables 5
- User s manual 5 one ide cable 5
- Ga 78lmt usb3 motherboard block diagram 6
- 1 installation precautions 7
- Chapter 1 hardware installation 7
- 2 product specifications 8
- 2 productspecifications 8
- 3 installing the cpu 10
- Installing the cpu 10
- 4 installing the memory 11
- 5 installing an expansion card 11
- Dualchannelmemoryconfiguration 11
- 6 back panel connectors 12
- D sub port 12
- Dvi d port 12
- Hdmi port 12
- Ps 2 keyboard mouse port 12
- Usb 2 1 port 12
- A dualdisplayconfigurations 13
- B playback of blu ra 13
- Line in jack blue 13
- Line out jack green 13
- Mic in jack pink 13
- Rj 45 lan port 13
- Usb 3 2 port 13
- 7 internal connectors 14
- 2 atx_12v_2x4 atx 2x4 12v power connector and 2x12 main power connector 15
- The 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 15
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 15
- With the use of the power connector the power supply can supply enough stable power to all the components onthemotherboard beforeconnectingthepowerconnector firstmakesurethepowersupplyisturned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation 15
- 4 cpu_fan sys_fan fan headers 16
- Bat battery 16
- Araid0orraid1configurationrequiresatleasttwoharddrives ifmorethantwoharddrives 17
- Araid10configurationrequiresfourharddrives 17
- Are to be used the total number of hard drives must be an even number 17
- Ide ide connector 17
- Pin no definition 17
- Sata2 0 1 2 3 4 5 sata 3gb s connectors controlled by amd sb710 south bridge 17
- The ide connector supports up to two ide devices such as hard drives and optical drives before attaching the ide cable locate the foolproof groove on the connector if you wish to connect two ide devices remember to set the jumpers and the cabling according to the role of the ide devices for example master or slave forinformationaboutconfiguringmaster slavesettingsfortheidedevices readtheinstructionsfromthe device manufacturers 17
- The sata connectors conform to sata 3gb s standard and are compatible with sata 1 gb s standard each sata connector supports a single sata device the amd sb710 controller supports raid 0 raid 1 raid10 andjbod refertochapter4 configuringsataharddrive s forinstructionsonconfiguring a raid array 17
- Ci chassis intrusion header connects to the chassis intrusion switch sensor on the chassis that can detect if the chassis cover has been removed this function requires a chassis with a chassis intrusion switch sensor 18
- Connect the power switch reset switch speaker chassis intrusion switch sensor and system status indicator on the chassis to this header according to the pin assignments below note the positive and negative pins before connecting the cables 18
- Connects to the power status indicator on the chassis front panel the led is on when the system is operating the led keeps blinking when the system is in s1 sleep state the led is off when the system is in s3 s4 sleep state or powered off s5 18
- F_panel front panel header 18
- Hd hard drive activity led connects to the hard drive activity led on the chassis front panel the led is on when the hard drive is reading or writing data 18
- Msg pwr message power sleep led 18
- Pw power switch connectstothepowerswitchonthechassisfrontpanel youmayconfigurethewaytoturnoffyour system using the power switch refer to chapter 2 bios setup power management for more information 18
- Res reset switch connects to the reset switch on the chassis front panel press the reset switch to restart the computer if the computer freezes and fails to perform a normal restart 18
- S1 blinking 18
- S3 s4 s5 off 18
- Speak speaker connects to the speaker on the chassis front panel the system reports system startup status by issuing a beep code one single short beep will be heard if no problem is detected at system startup if a problem is detected the bios may issue beeps in different patterns to indicate the problem 18
- System status led 18
- The front panel design may differ by chassis a front panel module mainly consists of power switch reset switch power led hard drive activity led speaker and etc when connecting your chassis front panel module to this header make sure the wire assignments and the pin assignments are matched correctly 18
- F_audio front panel audio header 19
- Instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 19
- Spdif_o s pdif out header 19
- The front panel audio header supports hd audio by default audio signals will be present on both of the front and back panel audio connections simultaneously some chassis provide a front panel audio module that has separated connectors on each wire 19
- Thefrontpanelaudioheadersupportsintelhighdefinitionaudio hd andac 97audio youmayconnect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 19
- This header supports digital s pdif out and connects a s pdif digital audio cable provided by expansion cards for digital audio output from your motherboard to certain expansion cards like graphics cards and sound cards for example some graphics cards may require you to use a s pdif digital audio cable for digital audio output from your motherboard to your graphics card if you wish to connect an hdmi display to the graphics card and have digital audio output from the hdmi display at the same time for information about connecting the s pdif digital audio cable carefully read the manual for your expansion card 19
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb header prior to installing the usb bracket be sure to turn off your computer and unplug the power cord 20
- F_usb1 f_usb2 usb 2 1 headers 20
- F_usb30 usb 3 2 header 20
- From the power outlet to prevent damage to the usb bracket 20
- Theheaderconformstousb3 2 specificationandcanprovidetwousbports forpurchasingthe optional 3 front panel that provides two usb 3 2 ports please contact the local dealer 20
- Theheadersconformtousb2 1 specification eachusbheadercanprovidetwousbportsviaan optional usb bracket for purchasing the optional usb bracket please contact the local dealer 20
- Com serial port header 21
- Lpt parallel port header 21
- The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 21
- The lpt header can provide one parallel port via an optional lpt port cable for purchasing the optional lpt port cable please contact the local dealer 21
- Clr_cmos clear cmos jumper 22
- 1 startup screen 23
- A the logo screen default 23
- B the post screen 23
- Chapter 2 bios setup 23
- 2 the main menu 24
- Access more advanced options 24
- F11 save cmos to bios 24
- F12 load cmos from bios 24
- Keys for the main menu only 24
- Samplebiosversion d1 24
- System to its defaults 24
- The bios setup menus described in this chapter are for reference only and may differ by bios 24
- To accept or enter a sub menu 24
- To complete 24
- Tocomplete 24
- Version 24
- When the system is not stable as usual select the load optimized defaults item to set your 24
- 3 mb intelligent tweaker m i t 25
- Allows you to determine whether to allocate system memory for the onboard graphics controller 25
- Disabled disables the onboard graphics controller 25
- Frame buffer size is the total amount of system memory allocated solely for the onboard graphics controller ms dos for example will use only this memory for display options are auto default 128mb 256mb 512mb 1024mb 25
- Igxconfiguration 25
- Internal graphics mode 25
- Note this item is present only when you install a cpu that supports this feature 25
- Uma allocates memory for the onboard graphics controller from the system memory default 25
- Uma frame buffer size 25
- Whether the system will work stably with the overclock overvoltage settings you made is dependent onyouroverallsystemconfigurations incorrectlydoingoverclock overvoltagemayresultindamage to cpu chipset or memory and reduce the useful life of these components this page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or other unexpected results inadequately altering the settings may result in system s failure to boot if this occurs clear the cmos values and reset the board to default values 25
- Core performance boos 26
- Cpb rati 26
- Cpu clock ratio 26
- Cpu frequency mhz 26
- Cpu host clock control 26
- Cpu northbridge freq 26
- Ht link width 26
- Onboard vga output connect 26
- Pcie clock mhz 26
- Surround view 26
- Turbo cp 26
- Vga core clock control 26
- Vga core clock mhz 26
- 1t 2t command timing 27
- Allows you to manually set the frequency for the ht link between the cpu and chipset 27
- Allows you to set memory control mode 27
- Auto bios will automatically adjust the ht link frequency default 27
- Cas latency 27
- Dcts mode 27
- Ddr3 timing items 27
- Determines whether to manually set the memory clock auto lets bios automatically set the memory clock as required manual allowsthememoryclockcontrolitembelowtobeconfigurable default 27
- Dramconfiguration 27
- Ganged sets memory control mode to single dual channel 27
- Ht link frequency 27
- Manual allowsalldramtimingcontrolitemsbelowtobeconfigurable 27
- Memory clock 27
- Minimum ras active time 27
- Options are auto default 15t 30t 27
- Options are auto default 1t 2t 27
- Options are auto default 4t 12t 27
- Options are auto default 5t 12t 27
- Options are auto default manual options are auto default manual 27
- Ras to cas r w delay 27
- Row precharge time 27
- Set memory clock 27
- Thisoptionisconfigurableonlywhen set memory clock is set to manual options are x4 0 x5 3 x6 6 x8 0 27
- Unganged sets memory control mode to two single channel default 27
- X1 x10 sets ht link frequency to x1 x10 200 mhz 2 ghz 27
- Channel interleaving 28
- Cpu voltage control 28
- Ddr3 voltage 28
- Dqs training control 28
- Memclock tri stating 28
- Northbridge volt control 28
- Precharge time 28
- Rank interleaving 28
- Ras to ras delay 28
- Row cycle time 28
- System voltage control 28
- Trfc0 for dimm1 dimm3 28
- Trfc1 for dimm2 dimm4 28
- Twtr command delay 28
- Write recovery time 28
- 4 standard cmos features 29
- Access mode sets the hard drive access mode options are auto default chs lba large 29
- Allows you to set the cpu north bridge vid voltage auto sets the cpu north bridge vid voltage as required the adjustable range is dependent on the cpu being installed default normal 29
- Auto lets the bios automatically detect ide sata devices during the post default 29
- Cpu nb vid control 29
- Date mm dd yy 29
- Displays the normal operating voltage of your cpu 29
- Displays the normal operating voltage of your cpu north bridge 29
- Extended ide drive configureyouride satadevices 29
- Ide channel 0 1 master slave 29
- Ide channel 0 1 master slave configureyouride satadevicesbyusingoneofthetwomethodsbelow byusingoneofthethree methods below 29
- Ide channel 2 3 master slave 29
- Manual allowsyoutomanuallyenterthespecificationsoftheharddrivewhentheharddrive access mode is set to chs 29
- None if no ide sata devices are used set this item to none so the system will skip the detection of the device during the post for faster system startup 29
- Normal cpu vcore 29
- Normal cpu vcore nb 29
- Note increasing cpu voltage may result in damage to your cpu or reduce the useful life of the cpu note increasing cpu voltage may result in damage to your cpu or reduce the useful life of the cpu 29
- Sets the system date 29
- Sets the system time 29
- Time hh mm ss 29
- 5 advanced bios features 30
- Access mode sets the hard drive access mode options are auto default large 30
- Allows you to determine whether the system will stop for an error during the post options are all errors no errors all but keyboard default 30
- Amd c1e support 30
- Capacity approximate capacity of the currently installed hard drive 30
- Disabled disables the c1e function default 30
- Enabled if a cpu that supports hardware c1e is installed the bios will automatically enable the hardware c1e function if not the bios will enable the software c1e function 30
- Enables or disables load line control this item allows you to adjust vdroop at different levels enabling load line calibration may keep the cpu voltage more constant under light and heavy cpu load auto letsthebiosautomaticallyconfigurethissetting default auto 30
- Enables or disables the c1e cpu power saving function in system halt state when enabled the power consumption will be reduced during system halt state 30
- Halt on 30
- Igxconfiguration 30
- Load line control 30
- Memory 30
- Note this item is present only when you install a cpu that supports this feature 30
- The settings in this submenu are synchronous to those under the same items on the mb intelligent tweaker m i t main menu 30
- Thesefieldsareread onlyandaredeterminedbythebiospost 30
- Virtualization 30
- Virtualization enhanced by virtualization technology will allow a platform to run multiple operating systems and applications in independent partitions with virtualization one computer system can function as multiple virtual systems default disabled 30
- Amd k8 cool quiet control 31
- Away mode 31
- Cpu core 0 31
- Cpu core 1 2 3 31
- Cpu core control 31
- Cpu unlock 31
- Efi cd dvd boot option 31
- First second third boot device 31
- Hard disk boot priority 31
- Hdd s m a r t capability 31
- Password check 31
- 6 integrated peripherals 32
- Ahci configuresthesatacontrollerstoahcimode advancedhostcontrollerinterface ahci isaninterfacespecificationthatallowsthestoragedrivertoenableadvanced serial ata features such as native command queuing and hot plug 32
- Allows you to determine whether to display the gigabyte logo at system startup disabled displays normal post message default enabled 32
- As sata type the mode depends on the onchip sata type settings 32
- Configurestheoperatingmodeoftheintegratedsatacontroller 32
- Enables or disables the integrated sata controllers default enabled 32
- Full screen logo show 32
- Ide disablesraidforthesatacontrollerandconfiguresthesatacontrollertopatamode default 32
- Init display first 32
- Native ide allows the sata controller to operate in native ide mode enable native ide mode if you wish to install operating systems that support native mode default 32
- Onchip sata controller 32
- Onchip sata port4 5 type sata2 4 sata2 5 connectors 32
- Onchip sata type sata2 0 sata2 3 connectors 32
- Onchipvga setstheonboardgraphicsasthefirstdisplay 32
- Pcislot setsthepcigraphicscardasthefirstdisplay default 32
- Peg setsthepciexpressgraphicscardonthepciex16slotasthefirstdisplay 32
- Raid enables raid for the sata controller 32
- Specifiesthefirstinitiationofthemonitordisplayfromtheinstalledpcigraphicscard pciexpressgraphics card or the onboard graphics 32
- Thisoptionisconfigurableonlywhen onchip sata type is set to raid or ahci configurestheoperating mode of the integrated sata2 4 sata2 5 connectors 32
- Allows you to decide whether to activate the boot rom integrated with the onboard lan chip default disabled 33
- Enables or disables the etron ej168 usb controller default enabled 33
- Enables or disables the onboard audio function default enabled 33
- Enables or disables the onboard lan function default enabled 33
- F_usb30 controller etron ej168 usb controller usb 3 2 ports routed to the 33
- If you wish to install a 3rd party add in audio card instead of using the onboard audio set this item to if you wish to install a 3rd party add in audio card instead of using the onboard audio set this item to disabled 33
- If you wish to install a 3rd party add in network card instead of using the onboard lan set this item to if you wish to install a 3rd party add in network card instead of using the onboard lan set this item to disabled 33
- Onboard audio function 33
- Onboard f_usb30 header 33
- Onboard lan boot rom 33
- Onboard lan function 33
- Onchip sata port as esp 33
- Port0 as esp port1 as esp port2 as esp port3 as esp 33
- Port4 as esp port5 as esp 33
- Smart lan lan cable diagnostic function 33
- This motherboard incorporates cable diagnostic feature designed to detect the status of the attached lan cable this feature will detect cabling issue and report the approximate distance to the fault or short 33
- Thisoptionisconfigurableonlywhen onchip sata type is set to ahci and onchip sata type port4 5 is set to as sata type enabled will speed up the hot plug detection of the connected sata device default disabled 33
- Thisoptionisconfigurableonlywhen onchip sata type is set to ahci enabled will speed up the hot plug detection of the connected sata device default disabled 33
- 7 power management setup 34
- Allows usb keyboard to be used in ms dos default enabled 34
- Determineswhethertodetectusbstoragedevices includingusbflashdrivesandusbharddrivesduring the post default enabled 34
- Disabled disabled will turn off all of the usb functionalities below 34
- Ecp mode use dma 34
- Enables or disables the etron ej168 usb controller default enabled 34
- Enables or disables the integrated usb controller default enabled 34
- Enablesordisablesthefirstserialportandspecifiesitsbasei oaddressandcorrespondinginterrupt 34
- Enablesordisablestheonboardparallelport lpt andspecifiesitsbasei oaddressandcorresponding interrupt options are 378 irq7 default 278 irq5 3bc irq7 disabled 34
- Note supported on windows 7 vista operating system only 34
- Onboard parallel port 34
- Onboard serial port 34
- Options are auto 3f8 irq4 default 2f8 irq3 3e8 irq4 2e8 irq3 disabled options are auto 3f8 irq4 default 2f8 irq3 3e8 irq4 2e8 irq3 disabled 34
- Parallel port mode 34
- R_usb30 controller etron ej168 usb controller usb 3 2 ports on the back panel 34
- Selects an operating mode for the onboard parallel lpt port options are spp standard parallel port default epp enhanced parallel port ecp extended capabilities port ecp epp 34
- Selectsdmachannelforthelptportinecpmode thisitemisconfigurableonlyif parallel port mode is set to ecp or ecp epp options are 3 default 1 34
- Usb controllers 34
- Usb legacy function 34
- Usb storage function 34
- Acpi suspend type 35
- Hpet support 35
- Kb power on password 35
- Modem ring resume 35
- Pme event wake up 35
- Power on by keyboard 35
- Power on by mouse 35
- Soft off by power button 35
- Usb wake up from s3 35
- 3 4 5 7 9 10 11 12 14 15 assignsirq3 4 5 7 9 10 11 12 14 15tothefirstpcislot 36
- 8 pnp pci configurations 36
- 8 pnp pciconfigurations 36
- 9 pc health status 36
- Ac back function 36
- Auto biosauto assignsirqtothefirstpcislot default 36
- Date ofmonth alarm turnonthesystemataspecifictimeoneachdayoronaspecificdayinamonth 36
- Determines the state of the system after the return of power from an ac power loss 36
- Determines whether to let the system consume least power in s5 shutdown state default disabled 36
- Determines whether to power on the system at a desired time default disabled 36
- Erp support 36
- Full on the system is turned on upon the return of the ac power 36
- If enabled set the date and time as following if enabled set the date and time as following 36
- Memory the system returns to its last known awake state upon the return of the ac power 36
- Note when this item is set to note when this item is set to enabled the following four functions will become unavailable power on by alarm pme event wake up power on by mouse power on by keyboard and wake on lan 36
- Note when using this function avoid inadequate shutdown from the operating system or removal of the note when using this function avoid inadequate shutdown from the operating system or removal of the ac power or the settings may not be effective 36
- Pci1 irq assignment 36
- Power on by alarm 36
- Resume time hh mm ss set the time at which the system will be powered on automatically 36
- Soft off the system stays off upon the return of the ac power default 36
- 10 load fail safe defaults 37
- Case opened 37
- Cpu smart fan control 37
- Cpu system fan fail warning 37
- Cpu warning temperature 37
- Current cpu system fan speed rpm 37
- Current system cpu temperature 37
- Current voltage v vcore ddr3 1 v 12v 3 v 37
- Hardware thermal control 37
- Reset case open status 37
- 11 load optimized defaults 38
- 12 set supervisor user password 38
- Again the message password disabled will appear indicating the password has been cancelled 38
- Key to load the optimal bios default settings the bios defaults settings help the system to operate in optimum state always load the optimized defaults after updating the bios or after clearing the cmos values 38
- Note beforesettingtheuserpassword besuretosettheadministratorpasswordfirst note beforesettingtheuserpassword besuretosettheadministratorpasswordfirst 38
- Supervisor password 38
- Thebiossetupprogram allows you to specify two separate passwords 38
- User password 38
- When a system password is set and the when a system password is set and the password check item in advanced bios features is set to setup you must enter the supervisor password for entering bios setup and making bios changes when the password check item is set to system you must enter the supervisor password or user password at system startup and when entering bios setup 38
- When the password check item is set to system you must enter the supervisor password or user password at system startup to continue system boot in bios setup you must enter the supervisor password if you wish to make changes to bios settings the user password only allows you to view the bios settings but not to make changes 38
- 13 save exit setup 39
- 14 exit without saving 39
- To return to the bios setup main menu 39
- A installing sata hard drive s in your computer 40
- Before you begin 40
- Chapter 3 drivers installation 40
- Chapter 4 appendix 40
- Configuring sata hard drive s 40
- Configuringsataharddrive s 40
- Configuringtheonboardsatacontroller 40
- B configuringsatacontrollermodeinbiossetup 41
- C configuringaraidarrayinraidbios 41
- A installing windows xp 42
- B installing windows 7 vista 42
- Installing the sata raid ahci driver and operating system 42
- Making a sata raid ahci driver diskette 42
- Our commitment to preserving the environment 43
- Regulatory notices 43
- Regulatory statements 43
- Restriction of hazardous substances rohs directive statement 43
- Waste electrical electronic equipment weee directive statement 43
- Weee symbol statement 43
- Contact us 44
- Gigabyte esupport 44
- To submit a technical or non technical sales marketing question please link to http esupport gigabyte com 44
Похожие устройства
- Gigabyte ga-78lmt-s2pt Инструкция по эксплуатации
- Gigabyte ga-78lmt-s2 Инструкция по эксплуатации
- Gigabyte ga-e350n win8 Инструкция по эксплуатации
- Gigabyte ga-e350n Инструкция по эксплуатации
- Gigabyte ga-b75m-d2v Инструкция по эксплуатации
- Gigabyte ga-z77-hd3 Инструкция по эксплуатации
- Gigabyte ga-h61m-ds2h Инструкция по эксплуатации
- Gigabyte gsmart aku a1 quad core white Инструкция по эксплуатации
- Gigabyte brix gb-bxi7-4500 Инструкция по эксплуатации
- Gigabyte gsmart roma r2 dual sim black Инструкция по эксплуатации
- Gigabyte ga-b85m-ds3h Инструкция по эксплуатации
- Gigabyte ga-b85m-d3v Инструкция по эксплуатации
- Gigabyte ga-b85m-d2v Инструкция по эксплуатации
- Gigabyte gsmart guru g1 black Инструкция по эксплуатации
- Gigabyte ga-78lmt-s2pv Инструкция по эксплуатации
- Gigabyte ga-f2a88xn-wifi Инструкция по эксплуатации
- Gigabyte ga-c1037un-eu Инструкция по эксплуатации
- Gigabyte ga-h81m-h Инструкция по эксплуатации
- Gigabyte ga-h81m-hd2 Инструкция по эксплуатации
- Gigabyte ga-h81n Инструкция по эксплуатации
Скачать
Случайные обсуждения
