Gigabyte ga-h97-gaming 3 [6/80] Box contents

- 6 -

Optional Items



2-portUSB2.0bracket(PartNo.12CR1-1UB030-6*R)



eSATAbracket(PartNo.12CF1-3SATPW-4*R)



3.5"FrontPanelwith2USB3.0/2.0ports(PartNo.12CR1-FPX582-2*R)



COMportcable(PartNo.12CF1-1CM001-3*R)



HDMI-to-DVIadapter(PartNo.12CT2-HDMI01-1*R)

The box contents above are for reference only and the actual items shall depend on the product package you

obtain. The box contents are subject to change without notice.

Box Contents

GA-H97-Gaming 3 motherboard

Motherboard driver disk

User's Manual

Four SATA cables

I/O Shield
