1-7 Internal Connectors

Read the following guidelines before connecting external devices:

• First make sure your devices are compliant with the connectors you wish to connect.

• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power

cord from the power outlet to prevent damage to the devices.

• After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

1) ATX

2) ATX_12V

3) CPU_FAN

4) SYS_FAN

5) SATA2 0/1/2/3

6) F_PANEL

7) F_AUDIO

8) F_USB1/2

9) BAT

10) CLR_CMOS

11) CI

12) SPEAKER

610
