Storage Interface Chipset:
- 2 x M.2 Socket 3 connectors
- 3 x SATA Express connectors
- 6 x SATA 6Gb/s connectors
- SupportforRAID0,RAID1,RAID5,andRAID10
* Referto"1-10InternalConnectors,"forthesupportedcongurationswiththeM.2,
SATA Express, and SATA connectors.
USB Chipset:
- 7 x USB 3.0/2.0 ports (3 ports on the back panel, 4 ports available through
the internal USB headers)
- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
Chipset+GENESYS LOGIC USB 2.0 Hub:
- 2 x USB 2.0/1.1 ports (available through the internal USB header)
Chipset+Intel
®
Thunderbolt
™
3 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 support
- 1 x USB 3.1 port on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
2 x M.2 Socket 3 connectors
3 x SATA Express connectors
6 x SATA 6Gb/s connectors
1 x CPU fan header
1 x water cooling fan header (CPU_OPT)
3 x system fan headers
1 x front panel header
1 x front panel audio header
2 x USB 3.0/2.0 headers
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header
1 x Thunderbolt
™
add-in card connector
1 x serial port header
1 x Clear CMOS jumper
1 x ECO button
1 x OC button
1 x audio gain control switch
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x DisplayPort
1 x HDMI port
1 x USB Type-C
™
port, with USB 3.1 support
1 x USB 3.1 port
3 x USB 3.0/2.0 ports
4 x USB 2.0/1.1 ports
2xRJ-45ports
1 x optical S/PDIF Out connector
5xaudiojacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
Line Out, Mic In)
- 7 -
