- 4 -
GA-H170-HD3 Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-H170-HD3 motherboard 5 Two SATA cables
5 Motherboard driver disk 5 I/O Shield
5 User's Manual 5 One G Connector
KB_MS_USB
CPU_FAN
ATX_12V_2X4
ATX
F_AUDIO
AUDIO
B_BIOS
PCIEX4
DDR4_2
DDR4_1
DDR4_4
DDR4_3
BAT
F_PANEL
COMA
Intel
®
H170
PCI2
CLR_CMOS
CODEC
M_BIOS
PCIEX1_1
PCIEX16
SPDIF_O
F_USB1
LGA1151
GA-H170-HD3
VGA
DVI
HDMI
R_USB30
USB30_LAN
SATA EXPRESS
F_USB30_2
PCIEX1_2
SATA3
iTE
®
Super I/O
SYS_FAN2
F_USB2LPT
SYS_FAN1
TPM
M2A_32G
Realtek
®
GbE LAN
SATA3
3 2
5 4
1 0
SATA EXPRESS
F_USB30_1
THB_C
PCI1
SYS_FAN3
PCIe to
PCI Bridge
80A
60A
42A
