 When installing different types of M.2 SSDs (including SATA SSDs and PCIe x2 SSDs), be sure to refer to

thesupportedcongurationsinthetablesbelowaccordingtotheoperatingmodeofyourSATAcontroller.

On the motherboard there are three length adjustment holes for the M.2 SSD. Select the proper hole

for the M.2 SSD to be installed and refasten the screw and nut.

6) M.2 (M.2 Socket 3 Connector)

The M.2 connector supports M.2 SATA SSDs and M.2 PCIe SSDs.

Follow the steps below to correctly install an M.2 SSD in the M.2 connector.

Step 1:

Use a screw driver to unfasten the screw and nut from the motherboard. Locate the proper mounting hole

M.2 SATA SSD

M.2 PCIe x2 SSD

a: Supported, r: Not supported.

Connector

Type of SSD
