1-7 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
12
1
4
1311
8
10
4
3
18
9
14 15
7
16
4
2
5
6
5
6
17
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3
5) SATA EXPRESS
6) SATA3 0/1/2/3/4/5
7) M2A_32G
8) BAT
9) F_PANEL
10) SPDIF_O
11) F_AUDIO
12) F_USB30_1/F_USB30_2
13) F_USB1/F_USB2
14) COMA
15) LPT
16) TPM
17) THB_C
18) CLR_CMOS
