Unique Features
- 102 -
5-2-9 V-Tuner
GIGABYTE V-Tuner
(Note1)
allowsyoutoeasilyne-tuneyourgraphicscardintheWindowsenvironment.You
can manually overclock the GPU and memory
(Note2)
or adjust the fan speed and power settings. It also allows
you to monitor your graphic card status at any time.
The V-Tuner Interface
Using V-Tuner
You can manually select the values of each item or use the sliders for adjustment and then click Apply. To set
the fan speed you need to select Manualrst.Youcansavethecurrentsettingstoaproleandcreateupto4
proles.Tocheckthegraphicscardstatus,youcanclickthe icon on the top right corner.
(Note1) BeforeusingV-Tuner,besuretoinstallthegraphicscarddriverrst.
(Note2) Adjustableitemsmayvarybygraphicscards.
