- 11 -
Hardware Installation
Storage Interface Chipset:
- 4xSATA6Gb/sconnectors(sSATA30~3),supportingIDEandAHCImodes
only
(AnoperatingsysteminstalledontheSATA30~5connectorscannotbeusedon
thesSATA30~3connectors.)
USB Chipset:
- 4xUSB3.0/2.0ports(2portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
- 8xUSB2.0/1.1ports(4portsonthebackpanel,4portsavailablethrough
theinternalUSBheaders)
Chipset + Renesas
®
uPD720210 USB 3.0 Hub:
- 4 x USB 3.0/2.0 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x PCIe power connector
1 x I/O shield audio LED power connector
1 x heatsink LED power connector
1 x M.2 Socket 3 connector
1 x SATA Express connector
10 x SATA 6Gb/s connectors
1 x CPU fan header
1xwatercoolingfanheader(CPU_OPT)
3 x system fan headers
1 x front panel header
1 x front panel audio header
1 x USB 3.0/2.0 header
2 x USB 2.0/1.1 headers
1 x Thunderbolt
™
add-in card connector
1 x Clear CMOS jumper
1 x CPU mode switch
1 x audio gain control switch
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
6 x USB 3.0/2.0 ports
4 x USB 2.0/1.1 ports
1 x optical S/PDIF Out connector
1 x RJ-45 port
5xaudiojacks(Center/SubwooferSpeakerOut,RearSpeakerOut,LineIn/Mic
In,LineOut,Headphone/SpeakerOutJack)
2 x Wi-Fi antenna connector holes
I/O Controller iTE
®
I/O Controller Chip
