- 4 -
GA-F2A88XM-HD3P Motherboard Layout
Box Contents
5 GA-F2A88XM-HD3P motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS_USB
AUDIO
Socket FM2+
ATX
GA-F2A88XM-HD3P
F_AUDIO
USB31_LAN
PCIEX4
DDR3_2
DDR3_1
BAT
LPT
SPDIF_O
ATX_12V
AMD A88X
SATA3
PCI
CODEC
PCIEX1
R_USB30
HDMI
PCIEX16
F_USB1 F_PANEL
M_BIOS
B_BIOS
CLR_CMOS
Realtek
®
GbE LAN
4
5
iTE
®
Super I/O
0
SYS_FAN
CPU_FAN
VGA
DVI
F_USB30
SATA3
6 7
SATA3
SATA3
2
3
SATA3
1
F_USB2
COM
ASMedia
®
USB 3.1 Controller
SPEAKER
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
