Application
Can be used in conjunction with:
• Pressurised storage heaters
• Thermally controlled instantaneous heaters
• Hydraulically controlled instantaneous heaters
Operation with low-pressure displacement water heaters is
not possible.
Specifications
• Flow pressure
- min. 1 bar
- recommended 1 - 5 bar
• Operating pressure max. 10 bar
• Test pressure 16 bar
If static pressure is greater than 5 bar, fit pressure reducer.
Avoid major pressure differences between hot and cold water
supply.
• Flow rate at 3 bar flow pressure:
- flow straightener approx. 20 l/min
• Temperature
Hot water inlet (maximum): 80 °C
Recommended (energy saving): 60 °C
• Water connection cold - right
hot - left
• Max. clamping length 60mm
Installation
Flush pipes thoroughly.
Installation and connection, see fold-out page III, Fig. [1].
Refer to the dimensional drawing on fold-out page I.
Note:
If the support plate (A) is omitted, the clamping length can be
increased by 15mm, see Fig. [1].
Connect sink mixer
The copper pipes must be connected to the service valves,
see Fig. [1].
- Cold-water connection (marked blue) = right
- Hot-water connection (marked red) = left
- Drinking water connection = Ø 10
Open cold and hot water supply and check connections
for leakage!
Operation
a) Lever
Pull lever = open (water flow)
Press lever down = closed
Turn lever right = cold water
Turn lever left = hot water
Water emerges at the flow straightener.
b) Stopcock for drinking water
Tap handle horizontal = valve closed
Turn tap handle counterclockwise = valve opens
Water emerges at the nozzle.
Flow rate limiter
This mixer is fitted with a flow rate limiter, permitting an
infinitely individual variable reduction in the flow rate.
The highest possible flow rate is set by the factory before
despatch.
The use of flow rate limiters in combination with hydraulic
instantaneous water heaters is not recommended.
For commissioning see “maintenance of the cartridge” point 1
to 3, Fig. [2] and [3].
Maintenance
Inspect and clean all parts, replace as necessary and grease
with Grohe special grease.
Shut off hot and cold water supply!
I. Cartridge, see Fig. [3].
1. Lever out plug (B).
2. Loosen set screw (C) with 3mm socket spanner and pull off
lever (D).
3. Unscrew cap (E).
4. Remove screws (G) and detach complete
cartridge (H).
5. Change complete cartridge (H).
Assemble in the reverse order.
Observe the correct installation position.
Make sure that the cartridge seals engage in the grooves on
the housing. Fit screws (G) and tighten evenly and
alternately.
II.Ceramic headpart, see Fig. [4].
1. Remove tap handle (J).
2. Pull off snap insert (K).
3. With a 17mm open-ended spanner, remove ceramic
headpart (L).
4. Replace ceramic headpart (L).
Assemble in the reverse order.
Before reinstallation of the tap handle close the headpart (L),
push on snap insert (K) and tap handle (J).
III. Unscrew and clean flow straightener (13 905), see fold-
out page II.
Assemble in reverse order.
Replacement parts, see fold-out page II ( * = special
accessories).
Care
For directions on the care of this fitting please refer to the
accompanying Care Instructions.
