Routes

A route is a sequence of waypoints or locations that leads you to

your final destination.

Creating and Navigating a Route Using the

Waypoint Map

The starting point can be your present location or another

location.

Select User Data > Routes > New > Use Waypoint Map.

Pan the waypoint map to select the starting location of the

route.

Follow the onscreen instructions to add a turns.

Select > Navigate To.

Select an option.

Editing a Saved Route

You can change the name of a route or change the turns the

route contains.

Select User Data > Routes.

Select a route.

Select Edit Route.

Select an option:

• To change the name, select Name, and enter the name.

• To select a waypoint from the turn list, select Edit Turns >

Use Turn List, and select a waypoint from the list.

• To select a turn using the chart, select Edit Turns > Use

Waypoint Map, and select a location on the chart.

Viewing a List of Routes

Select User Data > Routes.

Browsing for and Navigating a Saved Route

Before you can browse a list of routes and navigate to one of

them, you must create and save at least one route.

Select User Data > Routes.

Select a route.

Select Navigate To.

Select an option:

• To navigate the route from the starting point used when

the route was created, select Forward.

• To navigate the route from the destination point used

when the route was created, select Backward.

A magenta line appears. In the center of the magenta line is

a thinner purple line that represents the corrected course

from your present location to the destination. The corrected

course is dynamic, and it moves with your boat when you are

off course.

Review the course indicated by the magenta line.

Follow the magenta line along each leg in the route, steering

to avoid land, shallow water, and other obstacles.

If you are off course, follow the purple line (corrected course)

to go to your destination, or steer back to the magenta line

(direct course).

Deleting a Saved Route

Select User Data > Routes.

Select a route.

Select Delete.

Deleting All Saved Routes

Select User Data > Manage Data > Clear User Data >

Routes.

Track

A track is a recording of the current path of your boat. You can

show your current track in waypoint map view.

Setting the Color of the Track

Select User Data > Track > Track Options > Track Color.

Select a track color.

Clearing the Track

Select User Data > Track > Clear Track > OK.

Managing the Track Log Memory During

Recording

Select User Data > Track > Track Options.

Select Record Mode.

Select an option:

• To record a track log until the track memory is full, select

Fill.

• To continuously record a track log, replacing the oldest

track data with new data, select Wrap.

Configuring the Recording Interval of the

Track Log

You can indicate the frequency at which the track plot is

recorded. Recording more frequent plots is more accurate but

fills the track log faster. The resolution interval is recommended

for the most efficient use of memory.

Select User Data > Track > Track Options > Record

Intervals > Interval.

Select an option:

• To record the track based on a distance between points,

select Distance > Change, and enter the distance.

• To record the track based on a time interval, select Time >

Change, and enter the time interval.

• To record the track plot based on a variance from your

course, select Resolution > Change, and enter the

maximum error allowed from the true course before

recording a track point.

Deleting All Saved Waypoints, Routes, and

Tracks

Select User Data > Manage Data > Clear User Data > All >

OK.

Device Configuration

System Settings

Select Settings > System.

Display: Adjusts the backlight brightness (Adjusting the

Backlight, page 1) and color scheme (Adjusting the Color

Mode, page 1).

GPS: Provides information about the GPS satellite settings and

fix.

Language: Sets the on-screen language.

Simulator: Turns on the simulator and allows you to set the

speed and simulated location.

6 Routes
