GS1900 Series User’s Guide 178
CHAPTER 28
Configuration: Security
28.1 Overview
This section provides information for Security in Configuration.
28.2 Port Security
28.2.1 The Global Screen
Use this screen to view the Global settings. Click Configuration > Security > Port Security to
open this screen.
Figure 167 Configuration > Security > Port Security
The following table describes the labels in this screen.
28.2.2 The Port Screen
Use this screen to view the Port settings. Click Configuration > Security > Port Security >
Port to open this screen.
Table 134 Configuration > Security > Port Security
LABEL DESCRIPTION
Global
State Select the global security setting to be enabled or disabled.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard the changes.
