Epson WorkForce Pro WF-R5190DTW (RIPS) [10/38] Connecting a scanner to a network
![Epson WorkForce Pro WF-R5190DTW (RIPS) [10/38] Connecting a scanner to a network](/views2/1168620/page10/bga.png)
D
Select System Preferences from the Apple Menu.
E
Click the Print & Fax (10.5.x, 10.6.x) or Print & Scan (10.7.x or later) icon.
F
Click + under the Printers list.
G
For Mac OS X 10.5.x/10.6.x: Select the product name that you want to connect.
For Mac OS X 10.7.x or later: Select the product name that you want to connect, and then select the Epson
product name on the Use menu.
H
Click Add.
Note for Mac OS X 10.6.x or later users:
The printer driver is automatically downloaded by the Apple Software Updater.
I
Make sure your product is in the Printers list.
You can now use the product from your computer. If your product is a multifunctional printer equipped with a
scanner, follow the steps in the next section to connect the scanner to a network.
Connecting a scanner to a network
Follow the steps below to use a scanner from a computer by using EPSON Scan.
Note:
This feature is not available for all products or may not be enabled.
A
Download “EPSON Software Updater” from the following link.
http://support.epson.net/dnavi/
B
Launch “EPSON Software Updater”.
Available software is displayed as a list.
C
Select EPSON Scan, and then click Install.
Epson Scan is downloaded and installed.
D
Double-click Macintosh HD, Applications, Epson Software and then EPSON Scan Settings.
Note:
If the scanner is listed but cannot be selected immediately after the EPSON Scan Settings screen appears, wait for the
search to end.
E
Verify that the scanner is selected, select Network and then click Add.
Network Guide
Using Product via Network
10
