Chapter 34 Layer 2 Protocol Tunnel (L2PT) Commands
Ethernet Switch CLI Reference Guide
166
34.2 Command Examples
This example enables L2PT on the Switch and sets the destination MAC address for
encapsulating layer 2 protocol packets received on an access port.
l2protocol-tunnel point-to-
point udld
Enables point-to-point layer 2 protocol tunneling for
UDLD packets on the specified port(s).
C13
l2protocol-tunnel stp Enables layer 2 protocol tunneling for STP packets on
the specified port(s).
C13
l2protocol-tunnel vtp Enables layer 2 protocol tunneling for CDP packets on
the specified port(s).
C13
no l2protocol-tunnel Disables layer 2 protocol tunneling for CDP, VTP and
STP packets on the specified port(s).
C13
no l2protocol-tunnel cdp Disables layer 2 protocol tunneling for CDP packets on
the specified port(s).
C13
no l2protocol-tunnel point-to-
point
Disables point-to-point layer 2 protocol tunneling for
LACP, PAgP and UDLD packets on the specified port(s).
C13
no l2protocol-tunnel point-to-
point lacp
Disables point-to-point layer 2 protocol tunneling for
LACP packets on the specified port(s).
C13
no l2protocol-tunnel point-to-
point pagp
Disables point-to-point layer 2 protocol tunneling for
PAgP packets on the specified port(s).
C13
no l2protocol-tunnel point-to-
point udld
Enables point-to-point layer 2 protocol tunneling for
UDLD packets on the specified port(s).
C13
no l2protocol-tunnel stp Disables layer 2 protocol tunneling for STP packets on
the specified port(s).
C13
no l2protocol-tunnel vtp Disables layer 2 protocol tunneling for VTP packets on
the specified port(s).
C13
l2protocol-tunnel Enables layer 2 protocol tunneling on the Switch. C 13
l2protocol-tunnel mac <mac-addr> Sets the destination MAC address used for
encapsulating layer 2 protocol packets received on an
access port.
C13
no l2protocol-tunnel Disables layer 2 protocol tunneling on the Switch. C 13
show l2protocol-tunnel Displays layer 2 protocol tunneling settings and counters
for all ports.
E13
show l2protocol-tunnel interface
port-channel <port-list>
Displays layer 2 protocol tunneling settings and counters
for the specified port(s).
E13
Table 95 l2pt Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# configure
sysname(config)# l2protocol-tunnel
sysname(config)# l2protocol-tunnel mac 00:10:23:45:67:8e
sysname(config)#
