Zyxel GS2200-8HP [275/360] Static multicast commands
![Zyxel GS2200-8HP [275/360] Static multicast commands](/views2/1168652/page275/bg113.png)
Ethernet Switch CLI Reference Guide
275
CHAPTER 70
Static Multicast Commands
Use these commands to tell the Switch how to forward specific multicast frames to specific
port(s). You can also configure which to do with unknown multicast frames using the router
igmp unknown-multicast-frame command (see Table 65 on page 113).
70.1 Command Summary
The following section lists the commands for this feature.
Table 152 multicast-forward Command Summary
COMMAND DESCRIPTION M P
show mac address-table multicast Displays the multicast MAC address table. E 3
multicast-forward name <name>
mac <mac-addr> vlan <vlan-id>
inactive
Creates a new static multicast forwarding rule. The rule name
can be up to 32 printable ASCII characters.
mac-addr: Enter a multicast MAC address which identifies
the multicast group. The last binary bit of the first octet pair in
a multicast MAC address must be 1. For example, the first
octet pair 00000001 is 01 and 00000011 is 03 in
hexadecimal, so 01:00:5e:00:00:0A and 03:00:5e:00:00:27
are valid multicast MAC addresses.
vlan-id: A VLAN identification number.
Note: Static multicast addresses do not age out.
C13
multicast-forward name <name>
mac <mac-addr> vlan <vlan-id>
interface port-channel <port-
list>
Associates a static multicast forwarding rule with specified
port(s) within a specified VLAN.
C13
no multicast-forward mac <mac-
addr> vlan <vlan-id>
Removes a specified static multicast rule. C 13
no multicast-forward mac <mac-
addr> vlan <vlan-id> inactive
Activates a specified static multicast rule. C 13
