Zyxel GS2210-48 [178/351] Chapter 42 mac address commands
![Zyxel GS2210-48 [178/351] Chapter 42 mac address commands](/views2/1168827/page178/bgb2.png)
Chapter 42 MAC Address Commands
Ethernet Switch CLI Reference Guide
178
42.2 Command Examples
This example shows the current MAC address table.
The following table describes the labels in this screen.
mac-transfer dynamic-to-forward
interface port-channel <port-
list>
Displays and changes all MAC addresses dynamically
learned on the specified port(s) into static MAC addresses.
C13
mac-transfer dynamic-to-forward
vlan <vlan-list>
Displays and changes all dynamically learned MAC
addresses in the specified VLAN(s) into static MAC
addresses.
C13
Table 120 mac, mac-aging-time, and mac-flush Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# show mac address-table all
Port VLAN ID MAC Address Type
2 1 00:00:e8:7c:14:80 Dynamic
2 1 00:04:80:9b:78:00 Dynamic
2 1 00:0f:fe:ad:58:ab Dynamic
2 1 00:13:49:6b:10:55 Dynamic
2 1 00:13:d3:f0:7e:f0 Dynamic
2 1 00:18:f8:04:f5:67 Dynamic
2 1 00:80:c8:ef:81:d3 Dynamic
2 1 00:a0:c5:00:00:01 Dynamic
Table 121 show mac address-table
LABEL DESCRIPTION
Port This is the port from which the above MAC address was learned.
Drop: The entry is created from a filtering rule.
VLAN ID This is the VLAN group to which this frame belongs.
MAC Address This is the MAC address of the device from which this frame came.
Type This shows whether the MAC address is dynamic (learned by the Switch)
or static (manually entered using mac-forward commands, see Chapter
45 on page 183).
