Chapter 70 SNMP Server Commands
Ethernet Switch CLI Reference Guide
263
Table 169 snmp-server trap-destination enable traps Command Summary
COMMAND DESCRIPTION M P
snmp-server trap-destination
<ip> enable traps
Enables sending SNMP traps to a manager. C 13
no snmp-server trap-destination
<ip> enable traps
Disables sending of SNMP traps to a manager. C 13
snmp-server trap-destination
<ip> enable traps aaa
Sends all AAA traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps aaa
Prevents the Switch from sending any AAA traps to the
specified manager.
C13
snmp-server trap-destination
<ip> enable traps aaa <options>
Sends the specified AAA traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps aaa <options>
Prevents the Switch from sending the specified AAA traps to
the specified manager.
C13
snmp-server trap-destination
<ip> enable traps interface
Sends all interface traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps interface
Prevents the Switch from sending any interface traps to the
specified manager.
C13
snmp-server trap-destination
<ip> enable traps interface
<options>
Sends the specified interface traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps interface
<options>
Prevents the Switch from sending the specified interface
traps to the specified manager.
C13
snmp-server trap-destination
<ip> enable traps ip
Sends all IP traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps ip
Prevents the Switch from sending any IP traps to the
specified manager.
C13
snmp-server trap-destination
<ip> enable traps ip <options>
Sends the specified IP traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps ip <options>
Prevents the Switch from sending the specified IP traps to the
specified manager.
C13
snmp-server trap-destination
<ip> enable traps switch
Sends all switch traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps switch
Prevents the Switch from sending any switch traps to the
specified manager.
C13
snmp-server trap-destination
<ip> enable traps switch
<options>
Sends the specified switch traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps switch
<options>
Prevents the Switch from sending the specified switch traps
to the specified manager.
C13
snmp-server trap-destination
<ip> enable traps system
Sends all system traps to the specified manager. C 13
no snmp-server trap-destination
<ip> enable traps system
Prevents the Switch from sending any system traps to the
specified manager.
C13
