3
NWA5301-NJ
802.11 b/g/n Wall-Plate Unied Access Point
Specications
Model NWA5301-NJ
Product name 802.11 b/g/n Wall-Plate Unified Access Point
MainDesign
Wirelessfrequency 2.4 GHz
Radio 1
Antenna Embedded 2x2
RF Specifications
Frequencyband 2.4GHz(11g/n) 2.4 GHz (IEEE 802.11 b/g/n); USA (FCC): 2.412 to 2.462 GHz; Europe (ETSI): 2.412 to 2.472 GHz
802.11npremiumfeatures
• 2x2 multiple-input multiple-output (MIMO)
with two spatial streams
• Maximal Ratio Combining (MRC)
• 20- and 40-MHz channels
• PHY data rates up to 300 Mbps
• Packet aggregation: A-MPDU (Tx/Rx), A-MSDU
(Tx/Rx)
• Cyclic Delay diversity (CSD) support
Maximum transmit power
(Max.totalchannel)
US(FCC)2.4GHz 23 dBm, 2 antennas
EU(ETSI)2.4GHz 17 dBm, 2 antennas
Antenna gain 5 dBi
Support data rate
• 802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
• 802.11n: up to 300 Mbps in MCS15 (40 MHz; GI = 400 ns)
Receive sensitivity
2.4 GHz:
• 802.11b/g, min. up to -95 dBm
• 802.11n/20 MHz, min. up to -93 dBm
• 802.11n/40 MHz, min. up to -92 dBm
LAN
Numberof10/100Mbps
LAN ports
Uplink 1 x 10/100 Mbps POE port (PD)
Downlink 3 x 10/100 Mbps RJ-45 ports (including one PoE PSE)
PoE Yes
PoE power draw 13 W (Include 7 W for PoE PSE)
WLAN Security
WMM(Wi-Ficertified) Yes
WEP Yes
WPA/WPA2-PSK Yes
WPA2(Wi-Ficertified) Yes
WPA/WPA2-Enterprise Yes
EAP types TLS, TTLS, PEAP, FAST, AKA and SIM
NumberofmultipleSSID 8
IEEE802.1x Yes
MAC filtering Yes
Layer-2isolation Yes, multiple profiles
RADIUSauthentication Yes
Rogue AP detection Yes
Network
VLANs Yes
DHCPclient Yes
QoS
WMM Yes
WMM power saving Yes
ZyXEL ONE Network
ZONUtility
• Discovery of ZyXEL switches, APs and gateways*
• Centralized and batch configurations
■
IP configuration
■
IP renew
■
Device reboot
■
Device locating
■
Web GUI access
■
Firmware upgrade
■
Password configuration
■
One-click quick association with ZyXEL AP Configurator (ZAC)
Smart Connect
• Discover neighboring devices
• One-click remote management access to the neighboring ZyXEL devices
Management
ZAC
• Batch AP configuration
• Batch AP firmware upgrade
• Batch AP profile backup
Standalone AP mode Yes
Managed AP mode** Yes
CLI Yes
WebGUI Yes
SNMP Yes
* Gateway supporting ZON utility is scheduled for future release.
** Managed AP mode works with ZyXEL Controller with firmware version V4.10 or above.
