UAG4100/2100

Unied Access Gateway

Specications

Model UAG2100 UAG4100

HardwareSpecifications

10/100/1000MbpsRJ-45ports 4 x LAN, 1 x WAN

USBports 2

Max.concurrentsessions

*3

DHCPpoolsize

WLANManagement

Built-in WLAN controller Yes Yes

ManagedAPnumber(default/max.) 0/8 8/16

SSID 8 8

Standardcompliance 802.11 a/b/g/n

Wirelessthroughput(Mbps)

187 (2.4 GHz); 190 (5 GHz)

Max.outputpower(2.4GHz)

802.11b: 12.5 dBm @11 Mbps; 802.11g: 12 dBm @54 Mbps

802.11n: 12 dBm @20 MHz; 802.11n: 13 dBm @40 MHz

Max.outputpower(5GHz)

802.11n: 23 dBm @40 MHz

Radiosensitivity(2.4GHz)

Powerinput 12 V DC, 3 A max.

Max.powerconsumption(watt) 28

PhysicalSpecifications

Item

Dimensions(WxDxH)(mm/in.) 272 x 171 x 36/10.71 x 6.73 x 1.42

Weight (kg/lb.) 1.46/3.22

Packing

Dimensions(WxDxH)(mm/in.) 416 x 247 x 71/16.38 x 9.72 x 2.80

Weight (kg/lb.) 2.3/5.07

EnvironmentalSpecifications

Temperature -30°C to 70°C/-22°F to 158°F

Humidity 10% to 90% (non-condensing)

MTBF(hr) 497,644

Certifications

EMC FCC Part 15 (Class B), CE EMC (Class B), C-Tick (Class B), BSMI

Safety LVD (EN60950-1), BSMI

Note:

*1: Actual performance may vary depending on network conditions and activated applications.

*2: Routing throughput measured using the industry standard IXIA IxLoad testing tool (1,460-byte TCP packets).

*3: Maximum sessions measured using the industry standard IXIA IxLoad testing tool.
