Antennas and Cables
Model ANT2206 ANT2105
Product photo
Space Indoor Outdoor
Frequency band (MHz) 2400 - 2500 4900 - 5875 2400 - 2483 5150 - 5875
Gain 6 dBi 8 dBi 4.5 dBi 7 dBi
VSWR 2.0:1 Max. 2.0:1 Max. 2.0:1 Max. 2.0:1 Max.
Polarization Linear, vertical Linear, vertica Linear, vertical Linear, vertical
Radiation pattern:
H-plane
Radiation pattern:
V-plane
HPBW/Horizontal 65° 50° 360° 360°
HPBW/Vertical 75° 50° 30° 15°
Front to back ratio 12 dB -
Impedance 50 Ω 50 Ω
Connector RP-SMA plug N type plug
Survival wind speed - 216 km/hr
Temperature -10°C to 55°C/14°F to 131°F -10°C to 70°C/14°F to 158°F
Humidity 95% at 55°C (131°F) 95% at 55°C (131°F)
Radome color White, black White
Radome material ABS, UV resistant ABS
Dimensions
(WxDxH)(mm/in.)
76 x 86 x 118/2.99 x 3.39 x 4.65 f 22 x 183
Weight (g/lb.) 110/0.24 70/0.15
Accessory kit
• Screw kit
• Quick installation guide
-
