Appendix C Pop-up Windows, JavaScript and Java Permissions

LTE6101 User’s Guide

202

6 Click OK to close the window.

Figure 147 Security Settings - Java Scripting

Java Permissions

1 From Internet Explorer, click Tools, Internet Options and then the Security tab.

2 Click the Custom Level... button.

3 Scroll down to Microsoft VM.

4 Under Java permissions make sure that a safety level is selected.
