9
Cutlery Basket
Cutlery should be placed in the cutlery basket with handles at the bottom. If the rack has side baskets, the spoon should be
loaded individually into the appropriate slots, especially long utensils should be placed in the horizontal position at the front of
the upper basket as shown.
For personal safety and a top quality clean, place the silverware in the basket:
They do not nest together.
Place silverware with handles down.
But place knives and other potentially dangerous utensils handles-up.
Plate racks of Basket
The basket is fitted with plate racks which can be
stowed horizontal if required.
Cup shelf
The cup shelf could be stowed standing if
no cup being placed, which can set more place.
1 Forks
2 Soup spoons
3 Dessert spoons
4 Teaspoons
5 Knives
6 Serving spoons
7 Gravy ladles
8 Serving forks
WARNING!
■ Do not let any item extend through bottom.
■ Always load sharp utensils with the sharp point down!
6 1 6
2
1
1
1
2
5
55
1
2
5
5
1
4
3
3
3
3
4
4
4
7
3
5
4
4 8
3
2
2 2
IN
