LSI Corporation
- 17 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2012
Chapter 1: Overview
Hardware Specifications
Number of ports (continued) MegaRAID SAS 9260-8i RAID controller – Eight ports through two SFF-8087 x4 internal mini
SAS connectors
MegaRAID SAS 9260CV-4i RAID controller – Four ports through one SFF-8087 x4 internal
mini SAS connector
MegaRAID SAS 9260CV-8i RAID controller – Eight ports through two SFF-8087 x4 internal
mini SAS connectors
MegaRAID SAS 9260DE-8i RAID controller – Eight ports through two SFF-8087 x4 internal
mini SAS connectors
MegaRAID SAS 9260-16i RAID controller – Sixteen ports through four SFF-8087 x4 internal
mini SAS connectors
MegaRAID SAS 9261-8i RAID controller – Eight ports through two SFF-8087 mini-SAS
4i connectors
MegaRAID SAS 9265-8i RAID controller – Eight ports through two SFF-8087 x4 internal mini
SAS connectors
MegaRAID SAS 9265CV-8i RAID controller – Eight ports through two SFF-8087 x4 internal
mini SAS connectors
MegaRAID SAS 9266-4i RAID controller – Four ports through one SFF-8087 mini SAS 4i
internal connector
MegaRAID SAS 9266-8i RAID controller – Eight ports through two SFF-8087 mini SAS 4i
internal connectors
MegaRAID SAS 9270-8i RAID controller – Eight ports through two SFF-8087 mini SAS 4i
internal connectors
MegaRAID SAS 9271-4i RAID controller – Four ports through one SFF-8087 mini-SAS 4i
internal connector
MegaRAID SAS 9271-8i RAID controller – Eight internal SAS/SATA ports through two SFF-
8087 mini-SAS 4i internal connectors
MegaRAID SAS 9271-8iCC RAID controller – Eight internal SAS/SATA ports through two SFF-
8087 mini-SAS 4i internal connectors
MegaRAID SAS 9280-4i4e RAID controller – Four ports through one SFF-8087 x4 internal
mini SAS connector and four ports through one SFF-8088 x4 external mini SAS connector
MegaRAID SAS 9280-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
MegaRAID SAS 9280-16i4e RAID controller – Sixteen ports through four SFF-8087 x4
internal mini SAS connectors and four ports through one SFF-8088 x4 external mini
SAS connector
MegaRAID SAS 9280-24i4e RAID controller – Twenty-four ports through six SFF-8087 x4
internal mini SAS connectors and four ports through one SFF-8088 x4 external mini
SAS connector
MegaRAID SAS 9280DE-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
MegaRAID SAS 9285-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
MegaRAID SAS 9285CV-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
MegaRAID SAS 9286-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
MegaRAID SAS 9286CV-8e RAID controller – Eight internal SAS/SATA ports through two
SFF-8088 x4 mini external SAS connectors
MegaRAID SAS 9286CV-8e RAID controller – Eight internal SAS/SATA ports through two
SFF-8088 x4 mini external SAS connectors
Data transfer rate Up to 6Gb/s per PHY
Table 2 6Gb/s MegaRAID SATA+SAS RAID Controller Features (Continued)
Specification
MegaRAID SAS 9240, SAS 9260, SAS 9261, SAS 9265, SAS 9266, SAS 9270, SAS 9271,
SAS 9280, SAS 9285, and SAS 9286 RAID Controllers
