3.Removethecomputercover.See“Removingthecomputercover”onpage36.
4.Locatethehandlebar.See“Locatingcomponents”onpage12.
5.Removethetwoscrewsthatsecurethehandlebartothechassis,andthenslidethehandlebarto
disengageitfromthechassis.
Figure14.Removingthehandlebar
6.Toreinstallthehandlebar,alignthetwoscrewholesinthehandlebarwiththoseinthechassis,and
theninstallthescrewstosecurethehandlebartothechassis.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage68
.
RemovingandreinstallingtherearI/Oassembly
Attention:Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Important
safetyinformation”onpagev.
ThissectionprovidesinstructionsonhowtoremoveandreinstalltherearI/Oassembly.
ToremoveandreinstalltherearI/Oassembly,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.
2.Placeasoft,cleantowelorclothonthedeskorsurface.Holdthesidesofyourcomputerandgentlylay
itdownsothatthescreenisagainstthesurfaceandthecoverisfacingup.
3.Removethecomputercover.See“Removingthecomputercover”onpage36.
4.LocatetherearI/Oassembly.See“Locatingcomponents”onpage12.
5.Removethescrews1thatsecuretherearI/Oassemblytothechassis.Then,lifttherearI/Oassembly
upwardtoremoveitfromtherearI/Oassemblyslot.
Chapter5.Installingorreplacinghardware39
